Figure 6-1 Coral
FlexiCom 6032xx:
Main Cabinet Structure
and Card Slot
Assignments for a
3-shelf cabinet
Figure 6-2 Coral
FlexiCom 6048xx:
Main Cabinet Structure
and Card Slot
Assignments for a
4-shelf cabinet
6-2
Cabinet Descriptions
Universal
I/O slots
Shared
Service
or PB-ATS
slots
Peripheral
& ringer
power
supplies
Left
common
control
Right
common
control
Fan
tray
Universal
I/O slots
Shared
service
or PB-ATS
slots
Peripheral
& ringer
power
supplies
Left
common
control
Right
common
control
Fan
tray
