Cabling between the Control and Peripheral Shelves

...................................................................................................
The 32GC is the heart of the Coral FlexiCom 6000 system. A physical connection
must be constructed between the single 32GC or both 32GC cards and each peripheral
shelf, odd or even. The even peripheral shelves must have a hard-wire connection
between the PB-ATS cards and each 32GC card. These connections are implemented
via FC19 cables between the 32GCs piggybacked backplane card, the MPG-ATS and
the PB-ATSs backplane card, the PBD-ATS. The odd shelves make their connection
to the MPG-ATS via a PBD24S (located on the backplane of the odd shelf) connected
to their related PBD-ATSs on the even shelf via FC16 (100cm) or FC18
(50cm discontinued) cables. See Figure 2-15 for a wiring schematic.
The arrangement of these connections define the shelf numbering mainly used for the
Peripheral Shelf Numbering beginning
Programming Interface Updates and Displays. See
on page 6-26
for shelf numbering descriptions.
Main Cabinets (i.e., cabinets containing a Control Shelf) are shipped with factory
installed cabling between the main cabinet peripheral shelves and the Control Shelf.
The technician is required to wire the peripheral shelves from the other cabinets to the
Control Shelf. The hard wire connections are described below.
