Figure 4-1 CFD
Directory Display
Coral FlexiCom 6000 Installation Manual

Viewing CFD Directory Details

...................................................................................................
A list, or directory, of the files stored on the CFD may be displayed to determine its
contents. The CFD contains several files, including a system configuration database
and other files unique to the particular installation. For a Hot Standby system, each
system side may request to view its own directory.
1. From the Database Control Branch: Disk Menu (Route: 0, 10, 2, 0) , press 4 to
display the CFD file directory. The system prompts:
EXECUTE (Y/N) -
2. Press Y to display the list of files contained on the CFD, or press N to return
to the Database Disk menu. The PI command prompt ( *: ) returns immediately,
however the system processes the command as a background (low priority)
task.
Reading the directory generally takes only a few seconds, provided no other
priority tasks are required of the Main Processor.
typical CFD directory.
disk directory
FILE_NAME VERSION
1:DB0.DEF 2
2:DB1.DEF 1
3:DUMP 8224
4:DUMPCLA 8224
The directory display lists each file on the CFD. The FILE_NAME field identifies
each file. The VERSION field is a "store count" and indicates the relative age
compared to other files of the same type. The lowest version number indicates the
most recent, or the latest database file. The LAST_DATE and LAST_TIME fields
indicate the last date (in MM/DD/YY format) and time (in HH:MM:SS format) that
the file was written on the CFD. The FILE_STATUS field is valid only for database
files, and indicates whether or not the file was written successfully.
LAST_DATE LAST_TIME
mm/dd/yy 1:30:00
mm/dd/yy 14:00:10
0/0/0 0:0:0
0/0/0 0:0:0
Figure 4-1 illustrates a
FILE_STATUS
OK
OK
INVALID
INVALID
Software Installation Procedure
4-9
