Common Control Cards

BIOS Settings

...................................................................................................
The CLA-ATS card arrives at the customer site complete with an updated BIOS.
However, should the CLA-ATS card not function because of improper BIOS settings,
the BIOS can be updated by temporarily attaching a keyboard and terminal to the card.
The correct BIOS setup for the Teknor cPCI-MXP, Applicom T1005 BIOS Version 2.0
is described below.
BIOS Setup for Teknor cPCI-MXP, Applicom T1005, Version 2.0
1. Insert the CFD if not already inserted on the card component side panel.
2. Connect a video terminal and keyboard to the card front panel.
3. Insert the CLA-ATS back into its slot in the Control Shelf.
4. Press the CLA-ATS front panel reset button to re initialize the card.
5. Press the keyboard Delete or F2 key while the CLA-ATS card is initializing.
6. Follow the on screen directions to select items.
7. Choose the Standard CMOS SETUP option.
Should it be necessary to update the date and time, this may be changed on
this screen.
Primary Master, Primary Slave, Secondary Master and Secondary Slave
should all be set to AUTO .
Drive A and Drive B should be set to None .
8. Choose the BIOS FEATURES SETUP from the Main menu and verify the
following values for the items:
BIOS Option
Virus Warning
Quiet Post
Quick Power On Self Test
Full Screen LOGO Show
Boot from LAN First
Raid Card Boot First
Boot Sequence
Swap Floppy Drive
Boot Up Floppy Seek
Drive A Boot Permit
Value
Disabled
Disabled
Enabled
Disabled
Disabled
Disabled
C,A,SCSI
Disabled
Disabled
Enabled
