Table 2-3 Coral
System Power
Requirements
2-6
Hardware Installation Procedure
6. All equipment in the immediate vicinity shall be earthed the same way, and
shall not be earthed elsewhere.
7. The DC supply system is to be local, i.e. within the same premises as the
equipment.
8. A disconnect device is not allowed in the earthed circuit between the DC
supply source and the frame/earthed circuit connection.
Cabinet Type
Main with 2 Peripheral Shelves
Main with 3 Peripheral Shelves
2 Shelf Expansion
3 Shelf Expansion
4 Shelf Expansion
Branch Circuit for Auxiliary Branch
Coral Circuit
115
230 VAC
VAC
20A 10A 15A
20A 15A 15A
Add 10A Add 5A N/A
Add 15A Add 10A N/A
Add 20A Add 10A N/A
Coral FlexiCom 6000 Installation Manual
-48VDC
115 230
VAC VAC
10A 12A
10A 18A
N/A Add 12A
N/A Add 18A
N/A Add 24A
