11. Insert the replacement drive in the bay. The green latch at the front of the drive
12. When the black drive carrier lever begins to close by itself, push on it to lock the
13. Take the ESD strap off.
14. Replace the front bezel.
15. Resynchronize the new hard disk. Refer to
Replacing the four-fan assembly
The four-fan cooling assembly is not hot-swappable. You must power down the server and
disconnect it from the power supply.
When to replace the cooling fan assembly
When one or more of the four cooling fans is not turning, the remaining fans rotate faster to
maintain the same volume of air flow through the chassis. The hum of a cooling fan rotating
faster is both louder and higher in pitch than normal and indicates that the assembly must be
replaced. You cannot replace just one fan in the assembly.
To replace the four-fan assembly
1. Power down the server, unplug all peripheral devices and Ethernet cables, and
2. Attach the ESD strap to your wrist and attach the other end to a known grounded
3. Remove the chassis cover. Refer to
4. Remove the processor air duct. Refer to
5. Disconnect the fan connectors (A) from the front panel I/O board. Make of note of
Avaya CallPilot® 1005r Server Maintenance and Diagnostics
carrier must be to the right. Do not push on the black drive carrier lever until the
lever begins to close by itself.
drive assembly into place.
successful PEP installation
disconnect the AC power.
connection.
page 70 for instructions.
duct
on page 72 for instructions.
the order in which the fans are plugged into the board.
To synchronize the RAID after a
on page 96.
Removing and replacing the server cover
Removing and replacing the processor air
Replacing the four-fan assembly
December 2010
on
77
