Installing the Sensors

Sensor Installation Instructions

Sensor Installation Instructions
Note: Mounting toolkit SKF CMAC 9600-01 is for ¼-28 stud. Mounting toolkit SKF
CMAC 9600-02 is for the M8 adapter.
1. Drill a pilot hole (the drill bit is contained in the optional mounting toolkit).
Use #3 drill bit x 0.35 in. deep for ¼-28.
Use 6.7 mm drill bit x 8.9 mm deep for M8 adapter.
2. Using piloted endmill, make 1 in. (2.5 cm) diameter spot face. Use cutting fluid and
slow speed to extend endmill life.
3. Create threads in pilot hole using the bottom tap. Clean out hole and spot face
surface.
4. Apply thread locking compound to sensor mounting screw.
5. Thread sensor screw onto mounting surface, observing maximum torque
(24 lbf-in., 2.7 N-m).
6. Apply silicone dielectric grease to sensor connector socket. Fill connector half full
with dielectric grease.
7. Align the connector with the accelerometer socket key. Push connector firmly onto
accelerometer and screw on connector for the IP67 rating.
Note: Remove connector by pulling straight out, slightly wiggling the connector.
8. Install first cable restraint within 8 in. (20 cm) of sensor; install additional cable
restraints every 18 to 24 in. (45 to 60 cm).
9. Trim cable to length as needed.
