Configuring the SKF Multilog WVT with XML File Editor

DataController XML File Editor provides three tabs to edit three XML files, listed below.
The first two accomplish the initial configuration of the SKF Multilog WVT in the
network and are discussed in detail in this chapter. The third is discussed later in
Chapter 11, Modifying the Data Collection Schedule.
• WDMList.xml – configures the WDM Internet Protocol (IP) addresses and
Transmission Control Protocol (TCP) ports which DataController will use to connect
with the WDMs.
• GlobalConfig.xml – configures the common global default settings of the SKF
Multilog WVT devices. These settings are downloaded to the devices when they join
the network in their factory default state.
• SpectrumCollectNvs.xml – configures DataController's schedule for collecting the
trace spectra and time waves. This file is not created until after the first trend data
has been taken from the SKF Multilog WVT.
During the installation of DataController, the first two XML files are automatically
created and saved in the same place in the installation path where DataController is
installed. The default location of the WDMList.xml and GlobalConfig.xml files is
C:\Program Files (x86)\SKF-RS\Wireless Vibration Transmitter Data Controller – 7910.
The file SpectrumCollectNvs.xml is created later when the SKF Multilog WVT has taken
data. The default path is C:\Temp\DataController\Config.
Launching XML File Editor
You will launch XML File Editor to perform the initial configuration of the SKF Multilog
WVT.
WARNING! DataController works only in administrator mode in Windows 7
unless you are running in XP compatible mode.
To launch XML File Editor:
Go to Start > SKF > DataController and click XMLEditor. XML File Editor opens on
•
the WDMList tab.
