DataController and the WDM
Configuring the Measurement Units
To configure the Units Index, Temperature Overall:
•
Go to the WDM user interface web page.
•
In the Selection Panel, select the SKF Multilog WVT.
•
Click Inactivate in the Channel group in the ribbon bar to inactivate all channels at
one time.
•
In the Selection Panel, select the individual channel you want to modify.
•
In the Property Panel, expand Temperature Overall.
•
You can change the Units Index for the measurement to degrees Celsius (°C) or
Fahrenheit (°F). The default is degrees Celsius (°C).
•
Click Apply.
WARNING! Be sure to reactivate the channels only after you have finished
modifying all channel settings.
To configure the Units Index, Speed Overall:
•
Go to the WDM user interface web page.
•
In the Selection Panel, select the SKF Multilog WVT.
•
Click Inactivate in the Channel group in the ribbon bar to inactivate all channels at
one time.
•
In the Selection Panel, select the individual channel you want to modify.
•
In the Property Panel, expand Speed Overall.
8 - 8
Figure 8 - 12.
Temperature Overall, Units Index.
SKF Multilog On-line System WVT
User Manual
