Hardware Overview

Battery Conservation

• Flip the power switch PWR to the BAT position.
• Replace the cover.
WARNING! Dispose of used batteries according to your local regional
requirements.
Battery Conservation
Benchmark Configuration
Using our standard benchmark configuration in all four channels (shown below), the
projected battery life is up to five years, assuming there are no network issues and the
system is left unchanged throughout.
Benchmark Configuration
Trend Velocity
Trend Bearing
Trend Temperature
Trend Speed
Trend Bias Voltage
400 Line 1 kHz Velocity Spectra
800 Line 1 kHz Bearing Spectra
2048 Samples Bearing Waveform
2 - 12
batteries can be secured in the additional battery holder in a non-
hazardous area. Then, the battery holder with expended batteries
can be removed from the SKF Multilog WVT to be replaced with
the additional battery holder already loaded with fresh batteries.
 The SKF Multilog WVT always assumes that fully-charged
batteries have been inserted. The "gas gauge" is automatically
reset when batteries are changed. To ensure that the "gas gauge"
resets correctly, remove the exhausted batteries and wait at least
30 seconds before inserting fresh batteries.
Measurement Type Schedule
Hourly
Hourly
Hourly
Hourly
Daily
Daily
Daily
Monthly
SKF Multilog On-line System WVT
User Manual
