Hardware Overview
Internal Overview
Jumper Assignments
Release
Board Rev E
JP1
JP2
JP3
JP4
2 - 4
Figure 2 – 2.
SKF Multilog WVT Internal View.
DEFAULTS push button
USB port
IrDA port
Display
Battery holder
BAT/EXT switch
Four sensor input channels
Default Function
Not
PROGRAM
inserted
Not
TEST/RUN
inserted
Overall
Inserted
Current
Radio
Inserted
Current
Namur or isolated tacho input
External power connector
JP1
JP2
JP3
JP4
Description
Insert for USB programming.
1. Insert and apply power to enter autotester mode.
2. Insert with power applied and press green button to
enter COMMISSIONING mode.
Remove jumper and insert ammeter to measure
current to whole board from battery or external power.
Remove jumper and insert ammeter to measure
current to analog radio. Can also be used to power
cycle radio independently.
