User Manual Outline

This user manual presents the following topics in the subsequent chapters:
Chapter 2, Hardware Overview – covers the SKF Multilog WVT external and internal
details, connections, power sources, and specifications of the device and the
sensors.
Chapter 3, System Setup Checklist – provides a 1-page guideline to follow when setting
up the device in a OneWireless network.
Chapter 4, Setting Up the Network – covers network planning considerations and
provides procedures to connect network components, configure the WDM and PCN
network properties, and upload the Device Description file to the WDM.
Chapter 5, Setting Up the SKF Multilog WVT – presents the setup procedure, how to
commission the device, and how to mount the device and remote antenna.
Chapter 6, DataController Installation – includes an overview of the DataController
interface and covers installing DataController, and launching the Service Manager
service.
IMPORTANT: The SKF Multilog WVT must be initialized with the DataController
software.
Chapter 7, DataController and XML File Editor – describes how to set up global
configuration parameters to initialize the SKF Multilog WVT when the device joins
the network for the first time.
Chapter 8, DataController and the WDM – details how to configure the WDM's Gateway
Client Interface (GCI Server) to establish communication between DataController
and the WDM.
Chapter 9, Configuring the XML Import – shows how to configure the SKF @ptitude
Analyst > XML Import interface to import SKF Multilog WVT data from the
DataController software.
Chapter 10, Provisioning the Network Devices – describes provisioning network devices
and details both the over-the-air and handheld device methods.

SKF Multilog WVT Maintenance

Once the SKF Multilog WVT devices are installed and operating in the network, the
monitoring and maintenance of the system is generally performed through the WDM
User Interface (OneWireless). The Wireless Device Manager (WDM) User Interface User
Manual is provided as a separate document.
Refer to the Wireless Device Manager (WDM) User Interface User Manual, Chapter 9,
SKF Multilog WVT Maintenance, for the following maintenance operations:
• Restarting an SKF Multilog WVT in the network
• Replacing an SKF Multilog WVT in the network
• Removing an SKF Multilog WVT from the network
