memory map summary

Table 2 shows the memory map address ranges of the device. Internal memory is always located at address
0 and can be used as both program and data memory. The configuration registers for the common peripherals
are located at the same hex address ranges. The external memory address ranges in the device begin at the
address location 0x8000 0000.
MEMORY BLOCK DESCRIPTION
Internal RAM (L2)
Reserved
External Memory Interface (EMIF) Registers
L2 Registers
Reserved
McBSP 0 Registers
McBSP 1 Registers
Timer 0 Registers
Timer 1 Registers
Interrupt Selector Registers
Device Configuration Registers
Reserved
EDMA RAM and EDMA Registers
Reserved
GPIO Registers
Reserved
PLL Controller Registers
Reserved
QDMA Registers
Reserved
McBSP 0 Data/Peripheral Data Bus
McBSP 1 Data/Peripheral Data Bus
Reserved
Reserved
EMIF CE0 †
EMIF CE1 †
EMIF CE2 †
EMIF CE3 †
Reserved
† The number of EMIF address pins (EA[21:2]) limits the maximum addressable memory (SDRAM) to 128MB per CE space. To get 256MB of
addressable memory, additional general-purpose output pin or external logic is required.
12
Table 2. Memory Map Summary
BLOCK SIZE (BYTES)
64K
24M – 64K
256K
256K
256K
256K
256K
256K
256K
512
4
256K − 516
256K
768K
16K
480K
8K
4M + 520K
52
736M – 52
64M
64M
64M
1G + 64M
256M
256M
256M
256M
1G
•
