PLL and PLL controller (continued)
PLLCSR Register (0x01B7 C100)
28 27
31
15 12 11
Reserved
R−0
Legend: R = Read only, R/W = Read/Write; -n = value after reset
BIT # NAME
31:7 Reserved
6 STABLE
5:4 Reserved
3 PLLRST
2 Reserved
1 PLLPWRDN
0 PLLEN
FLOATING POINT DIGITAL SIGNAL PROCESSOR
24 23
Reserved
R−0
8 7 6
STABLE
R−x
Table 28. PLL Control/Status Register (PLLCSR)
Reserved. Read-only, writes have no effect.
Clock Input Stable. This bit indicates if the clock input has stabilized.
0 – Clock input not yet stable. Clock counter is not finished counting (default).
1 – Clock input stable.
Reserved. Read-only, writes have no effect.
Asserts RESET to PLL
0 – PLL Reset Released.
1 – PLL Reset Asserted (default).
Reserved. The user must write a "0" to this bit.
Select PLL Power Down
0 – PLL Operational (default).
1 – PLL Placed in Power-Down State.
PLL Mode Enable
0 – Bypass Mode (default). PLL disabled.
Divider D0 and PLL are bypassed. SYSCLK1/SYSCLK2/SYSCLK3 are divided down
directly from input reference clock.
1 – PLL Enabled.
Divider D0 and PLL are not bypassed. SYSCLK1/SYSCLK2/SYSCLK3 are divided down
from PLL output.
•
