timing requirements for synchronous DRAM cycles
NO. NO.
6 t su(EDV-EKOH) Setup time, read EDx valid before ECLKOUT high
7 t h(EKOH-EDV) Hold time, read EDx valid after ECLKOUT high
† The SDRAM interface takes advantage of the internal burst counter in the SDRAM. Accesses default to incrementing 4-word bursts, but random
bursts and decrementing bursts are done by interrupting bursts in progress. All burst types can sustain continuous data flow.
switching characteristics over recommended operating conditions for synchronous DRAM
†‡
cycles (see Figure 30−Figure 36)
NO. NO.
1 t d(EKOH-CEV)
2 t d(EKOH-BEV)
3 t d(EKOH-BEIV)
4 t d(EKOH-EAV)
5 t d(EKOH-EAIV)
8 t d(EKOH-CASV)
9 t d(EKOH-EDV)
10 t d(EKOH-EDIV)
11 t d(EKOH-WEV)
12 t d(EKOH-RAS)
† The SDRAM interface takes advantage of the internal burst counter in the SDRAM. Accesses default to incrementing 4-word bursts, but random
bursts and decrementing bursts are done by interrupting bursts in progress. All burst types can sustain continuous data flow.
‡ ARE/SDCAS/SSADS, AWE/SDWE/SSWE, and AOE/SDRAS/SSOE operate as SDCAS, SDWE, and SDRAS, respectively, during SDRAM
accesses.

SYNCHRONOUS DRAM TIMING

PARAMETER PARAMETER
Delay time, ECLKOUT high to CEx valid
Delay time, ECLKOUT high to BEx valid
Delay time, ECLKOUT high to BEx invalid
Delay time, ECLKOUT high to EAx valid
Delay time, ECLKOUT high to EAx invalid
Delay time, ECLKOUT high to ARE/SDCAS/SSADS valid
Delay time, ECLKOUT high to EDx valid
Delay time, ECLKOUT high to EDx invalid
Delay time, ECLKOUT high to AWE/SDWE/SSWE valid
Delay time, ECLKOUT high to, AOE/SDRAS/SSOE valid
POST OFFICE BOX 1443
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
†
(see Figure 30)
•
HOUSTON, TEXAS 77251−1443
TMS320C6712D
-150
UNIT UNIT
MIN MAX
1.5 ns
2.5 ns
−150
UNIT UNIT
MIN MAX
1.5 7 ns
7 ns
1.5 ns
7 ns
1.5 ns
1.5 7 ns
7 ns
1.5 ns
1.5 7 ns
1.5 7 ns
75
