TMS320C6712D
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
PIN
NO.
SIGNAL SIGNAL
NAME
GDP/
ZDP
ED9 P18
ED8 N20
ED7 N19
ED6 N18
ED5 M20
ED4 M19
ED3 L19
ED2 L18
ED1 K19
ED0 K18
TOUT1 F1
TINP1 F2
TOUT0 G1
TINP0 G2
CLKS1 E1
CLKR1 M1
CLKX1 L3
DR1 M2
DX1 L2
FSR1 M3
FSX1 L1
† I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal (PLL Filter)
‡ IPD = Internal pulldown, IPU = Internal pullup. [To oppose the supply rail on these IPD/IPU signal pins, use external pullup or pulldown resistors
no greater than 4.4 kΩ and 2.0 kΩ, respectively.]
# To maintain signal integrity for the EMIF signals, serial termination resistors should be inserted into all EMIF output signal lines.
28
Terminal Functions (Continued)
IPD/ IPD/
TYPE † TYPE †
IPU ‡ ‡
EMIF − DATA (CONTINUED) #
I/O/Z I/O/Z IPU IPU External data External data
I/O/Z I/O/Z IPU IPU External data External data
O IPD Timer 1 or general-purpose output
I IPD Timer 1 or general-purpose input
O IPD Timer 0 or general-purpose output
I IPD Timer 0 or general-purpose input
MULTICHANNEL BUFFERED SERIAL PORT 1 (McBSP1)
External clock source (as opposed to internal)
On this device, this pin does not have an internal pulldown (IPD). For proper device opera-
tion, the CLKS1 pin should either be driven externally at all times or be pulled up with a
I IPD
10-kΩ resistor to a valid logic level. Because it is common for some ICs to 3-state their out-
puts at times, a 10-kΩ pullup resistor may be desirable even when an external device is
driving the pin.
I/O/Z IPD Receive clock
I/O/Z IPD Transmit clock
Receive data
On this device, this pin does not have an internal pullup (IPU). For proper device operation,
I IPU the DR1 pin should either be driven externally at all times or be pulled up with a 10-kΩ resis-
tor to a valid logic level. Because it is common for some ICs to 3-state their outputs at times,
a 10-kΩ pullup resistor may be desirable even when an external device is driving the pin.
O/Z IPU Transmit data
I/O/Z IPD Receive frame sync
I/O/Z IPD Transmit frame sync
