TMS320C6712D
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
PARAMETER MEASUREMENT INFORMATION (CONTINUED)
AC transient rise/fall time specifications
Figure 18 and Figure 19 show the AC transient specifications for Rise and Fall Time. For device-specific
information on these values, refer to the Recommended Operating Conditions section of this Data Sheet.
t = 0.3 t c (max) †
Ground
† t c = the peripheral cycle time.
V US (max)
† t c = the peripheral cycle time.
64
Minimum
Risetime
Waveform
Valid Region
Figure 18. AC Transient Specification Rise Time
Figure 19. AC Transient Specification Fall Time
POST OFFICE BOX 1443
HOUSTON, TEXAS 77251−1443
V OS (max)
V IH (min)
t = 0.3 t c (max) †
V IL (max)
Ground
