TMS320C6712D
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
PLL and PLL controller (continued)
PLLM Register (0x01B7 C110)
28 27
31
15
12 11
Legend: R = Read only, R/W = Read/Write; -n = value after reset
BIT #
NAME
31:5
Reserved
4:0
PLLM
50
24 23
Reserved
R−0
8
7
Reserved
R−0
Table 29. PLL Multiplier Control Register (PLLM)
Reserved. Read-only, writes have no effect.
PLL multiply mode [default is x7 (0 0111)].
00000 =
Reserved
10000
00001 =
Reserved
10001
00010 =
Reserved
10010
00011 =
Reserved
10011
00100 =
x4
10100
00101 =
x5
10101
00110 =
x6
10110
00111 =
x7
10111
01000 =
x8
11000
01001 =
x9
11001
01010 =
x10
11010
01011 =
x11
11011
01100 =
x12
11100
01101 =
x13
11101
01110 =
x14
11110
01111
=
x15
11111
PLLM select values 00000 through 00011 and 11010 through 11111 are not supported.
•
POST OFFICE BOX 1443
HOUSTON, TEXAS 77251−1443
20 19
6
5
4
3
DESCRIPTION
=
x16
=
x17
=
x18
=
x19
=
x20
=
x21
=
x22
=
x23
=
x24
=
x25
=
Reserved
=
Reserved
=
Reserved
=
Reserved
=
Reserved
=
Reserved
16
2
1
0
PLLM
R/W−0 0111
