TMS320C6712D
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
ECLKOUT
CEx
BE[3:0]
EA[21:2]
ED[31:0]
AOE/SDRAS/SSOE †
ARE/SDCAS/SSADS †
AWE/SDWE/SSWE †
ARDY
† AOE/SDRAS/SSOE, ARE/SDCAS/SSADS, and AWE/SDWE/SSWE operate as AOE (identified under select signals), ARE, and AWE,
respectively, during asynchronous memory accesses.
72
ASYNCHRONOUS MEMORY TIMING (CONTINUED)
Setup = 2
Strobe = 3
8
8
8
11
10
6
Figure 27. Asynchronous Memory Write Timing
•
POST OFFICE BOX 1443
Not Ready
BE
Address
Write Data
7
HOUSTON, TEXAS 77251−1443
Hold = 2
9
9
9
9
10
7
6
