TMS320C6712D
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
PIN
NO.
SIGNAL SIGNAL
NAME
GDP/
ZDP
RSV A5
RSV N2
RSV N1
RSV B5
RSV D7
RSV A12
RSV B11
A15
A16
A18
B14
B16
B18
C14
C16
C17
D18
D20
E18
E19
RSV RSV
E20
F18
F20
G18
G19
G20
H19
H20
J20
N3
P1
P2
P3
† I = Input, O = Output, Z = High impedance, S = Supply voltage, GND = Ground, A = Analog signal (PLL Filter)
30
Terminal Functions (Continued)
IPD/ IPD/
TYPE † TYPE †
IPU
O IPU Reserved (leave unconnected, do not connect to power or ground)
Reserved. For proper device operation, this pin must be externally pulled up with a 10-kΩ
O
resistor.
Reserved. For proper device operation, this pin must be externally pulled up with a 10-kΩ
resistor.
Reserved (leave unconnected, do not connect to power or ground)
IPD Reserved (leave unconnected, do not connect to power or ground)
Reserved. [For new designs, it is recommended that this pin be connected directly to CV DD
(core power). For old designs, this can be left unconnected.
Reserved [For new designs, it is recommended that this pin be connected directly to V ss
(ground). For old designs, this pin can be left unconnected.
ADDITIONAL RESERVED FOR TEST
Reserved (leave unconnected, do not connect to power or ground) Reserved (leave unconnected, do not connect to power or ground)
