TMS320C6712D
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
peripheral register descriptions (continued)
HEX ADDRESS RANGE
01B7 C000
01B7 C004 − 01B7 C0FF
01B7 C100
01B7 C104 − 01B7 C10F
01B7 C110
01B7 C114
01B7 C118
01B7 C11C
01B7 C120
01B7 C124
01B7 C128 − 01B7 DFFF
HEX ADDRESS RANGE
01B0 0000
01B0 0004
01B0 0008
01B0 000C
01B0 0010
01B0 0014
01B0 0018
01B0 001C
01B0 0020
01B0 0024
01B0 0028 − 01B0 3FFF
16
Table 10. PLL Controller Registers
ACRONYM REGISTER NAME
PLLPID Peripheral identification register (PID)
− Reserved
PLLCSR PLL control/status register
− Reserved
PLLM PLL multiplier control register
PLLDIV0 PLL controller divider 0 register
PLLDIV1 PLL controller divider 1 register
PLLDIV2 PLL controller divider 2 register
PLLDIV3 PLL controller divider 3 register
OSCDIV1 Oscillator divider 1 register
− Reserved
Table 11. GPIO Registers
ACRONYM
GPEN GPIO enable register
GPDIR GPIO direction register
GPVAL GPIO value register
− Reserved
GPDH GPIO delta high register
GPHM GPIO high mask register
GPDL GPIO delta low register
GPLM GPIO low mask register
GPGC GPIO global control register
GPPOL GPIO interrupt polarity register
− Reserved
