peripheral register descriptions

Table 3 through Table 13 identify the peripheral registers for the device by their register names, acronyms, and
hex address or hex address range. For more detailed information on the register contents, bit names, and their
descriptions, see the specific peripheral reference guide listed in the TMS320C6000 DSP Peripherals Overview
Reference Guide (literature number SPRU190).
HEX ADDRESS RANGE
0180 0000
0180 0004
0180 0008
0180 000C
0180 0010
0180 0014
0180 0018
0180 001C
0180 0020
0180 0024 − 0183 FFFF
HEX ADDRESS RANGE
0184 0000
0184 4000
0184 4004
0184 4010
0184 4014
0184 4020
0184 4024
0184 4030
0184 4034
0184 5000
0184 5004
0184 8200
0184 8204
0184 8208
0184 820C
0184 8240
0184 8244
0184 8248
0184 824C
0184 8280
0184 8284
0184 8288
0184 828C
0184 82C0
0184 82C4
0184 82C8
0184 82CC
0184 82D0 − 0187 FFFF
Table 3. EMIF Registers
ACRONYM
GBLCTL EMIF global control
CECTL1 EMIF CE1 space control
CECTL0 EMIF CE0 space control
− Reserved
CECTL2 EMIF CE2 space control
CECTL3 EMIF CE3 space control
SDCTL EMIF SDRAM control
SDTIM EMIF SDRAM refresh control
SDEXT EMIF SDRAM extension
− Reserved
Table 4. L2 Cache Registers
ACRONYM
CCFG Cache configuration register
L2WBAR L2 writeback base address register
L2WWC L2 writeback word count register
L2WIBAR L2 writeback-invalidate base address register
L2WIWC L2 writeback-invalidate word count register
L1PIBAR L1P invalidate base address register
L1PIWC L1P invalidate word count register
L1DWIBAR L1D writeback-invalidate base address register
L1DWIWC L1D writeback-invalidate word count register
L2WB L2 writeback all register
L2WBINV L2 writeback-invalidate all register
MAR0 Controls CE0 range 8000 0000 − 80FF FFFF
MAR1 Controls CE0 range 8100 0000 − 81FF FFFF
MAR2 Controls CE0 range 8200 0000 − 82FF FFFF
MAR3 Controls CE0 range 8300 0000 − 83FF FFFF
MAR4 Controls CE1 range 9000 0000 − 90FF FFFF
MAR5 Controls CE1 range 9100 0000 − 91FF FFFF
MAR6 Controls CE1 range 9200 0000 − 92FF FFFF
MAR7 Controls CE1 range 9300 0000 − 93FF FFFF
MAR8 Controls CE2 range A000 0000 − A0FF FFFF
MAR9 Controls CE2 range A100 0000 − A1FF FFFF
MAR10 Controls CE2 range A200 0000 − A2FF FFFF
MAR11 Controls CE2 range A300 0000 − A3FF FFFF
MAR12 Controls CE3 range B000 0000 − B0FF FFFF
MAR13 Controls CE3 range B100 0000 − B1FF FFFF
MAR14 Controls CE3 range B200 0000 − B2FF FFFF
MAR15 Controls CE3 range B300 0000 − B3FF FFFF
− Reserved
