peripheral register descriptions (continued)
HEX ADDRESS RANGE
TIMER 0
0194 0000
0194 0004
0194 0008
0194 000C − 0197 FFFF
HEX ADDRESS RANGE
McBSP0
018C 0000
3000 0000 − 33FF FFFF
018C 0004
3000 0000 − 33FF FFFF
018C 0008
018C 000C
018C 0010
018C 0014
018C 0018
018C 001C
018C 0020
018C 0024
018C 0028 − 018F FFFF
Table 12. Timer 0 and Timer 1 Registers
ACRONYM ACRONYM
TIMER 1
0198 0000
0198 0004
0198 0008
0198 000C − 019B FFFF
Table 13. McBSP0 and McBSP1 Registers
ACRONYM ACRONYM
McBSP1
0190 0000
3400 0000 − 37FF FFFF
0190 0004
3400 0000 − 37FF FFFF
0190 0008
0190 000C
0190 0010
0190 0014
0190 0018
0190 001C
0190 0020
0190 0024
0190 0028 − 0193 FFFF
POST OFFICE BOX 1443
FLOATING POINT DIGITAL SIGNAL PROCESSOR
SPRS293A − OCTOBER 2005 − REVISED NOVEMBER 2005
REGISTER NAME REGISTER NAME
CTLx Timer x control register
PRDx Timer x period register
CNTx Timer x counter register
− Reserved
REGISTER DESCRIPTION REGISTER DESCRIPTION
McBSPx data receive register via Configuration Bus
DRRx
The CPU and EDMA controller can only read this register;
they cannot write to it.
DRRx McBSPx data receive register via Peripheral Data Bus
DXRx McBSPx data transmit register via Configuration Bus
DXRx McBSPx data transmit register via Peripheral Data Bus
SPCRx McBSPx serial port control register
RCRx McBSPx receive control register
XCRx McBSPx transmit control register
SRGRx McBSPx sample rate generator register
MCRx McBSPx multichannel control register
RCERx McBSPx receive channel enable register
XCERx McBSPx transmit channel enable register
PCRx McBSPx pin control register
− Reserved
•
HOUSTON, TEXAS 77251−1443
TMS320C6712D
COMMENTS COMMENTS
Determines the operating
mode of the timer, monitors the
timer status, and controls the
function of the TOUT pin.
Contains the number of timer
input clock cycles to count.
This number controls the
TSTAT signal frequency.
Contains the current value of
the incrementing counter.
−
