How to Programme

4.2 Quick Setup

0-01 Language
Option: Function:
Defines the language to be used in the
display. The frequency converter can be
delivered with 4 different language
packages. English and German are
included in all packages. English cannot
be erased or manipulated.
[0] English Part of Language packages 1 - 4
*
[1] Deutsch Part of Language packages 1 - 4
[2] Francais Part of Language package 1
[3] Dansk Part of Language package 1
[4] Spanish Part of Language package 1
[5] Italiano Part of Language package 1
Svenska Part of Language package 1
[7] Nederlands Part of Language package 1
[10] Chinese Part of Language package 2
Suomi Part of Language package 1
[22] English US Part of Language package 4
Greek Part of Language package 4
Bras.port Part of Language package 4
Slovenian Part of Language package 3
Korean Part of Language package 2
Japanese Part of Language package 2
Turkish Part of Language package 4
Trad.Chinese Part of Language package 2
Bulgarian Part of Language package 3
Srpski Part of Language package 3
Romanian Part of Language package 3
Magyar Part of Language package 3
Czech Part of Language package 3
Polski Part of Language package 4
Russian Part of Language package 3
Thai Part of Language package 2
Bahasa Indonesia Part of Language package 2
[52] Hrvatski
1-20 Motor Power [kW]
Range:
Application dependent [Application dependant]
*
VLT ® Automation Drive FC 300 12-Pulse
Operating Instructions High Power
1-22 Motor Voltage
Range:
Size
related
1-23 Motor Frequency
Range:
Application
dependent
1-24 Motor Current
Range:
Size
related
NOTE
This parameter cannot be changed while the motor is
running.
1-25 Motor Nominal Speed
Range:
Size related
NOTE
This parameter cannot be changed while the motor is
running.
Function:
®
MG34Q202 - VLT is a registered Danfoss trademark
Function:
[ 10. - Enter the nominal motor voltage
1000. V] according to the motor nameplate
*
data. The default value corresponds to
the nominal rated output of the unit.
This parameter cannot be adjusted
while the motor is running.
Function:
[20 - Min - Max motor frequency: 20-1000 Hz.
1000 Select the motor frequency value from
*
Hz] the motor nameplate data. If a value
different from 50 Hz or 60 Hz is selected,
it is necessary to adapt the load
independent settings in 1-50 Motor
Magnetisation at Zero Speed to 1-53 Model
Shift Frequency. For 87 Hz operation with
230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt 4-13 Motor
Speed High Limit [RPM] and
3-03 Maximum Reference to the 87 Hz
application.
Function:
[ 0.10 - Enter the nominal motor current
10000.00 A] value from the motor nameplate
*
data. This data is used for
calculating motor torque, motor
thermal protection etc.
Function:
[100 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
4 4
