Figure 3-9: Power Switch, Fuses, and Connection Ports
Item
1
2
3
4
5
WARNING!
instrument is not air-tight, and so gas can escape into the atmosphere surrounding
the instrument. When using potentially toxic gas, always observe the applicable
cautionary procedures as defined by your safety officer to maintain a safe working
environment.
5014038 E
Description
USB port
Gas inlet quick-connect fitting
Power switch
Fuse carrier
Power port
Use a compressed gas supply in a well-ventilated area. The
Chapter 3: Unpacking and Setting Up the Instrument
1
2
3
4
5
