SpectraMax Paradigm Multi-Mode Detection Platform User Guide
Measurement Specifications
The specifications for measurements using the Glow Luminescence (LUM) Detection
Cartridges are shown in the following table.
Table 5-23: Measurement Specifications for Glow Luminescence (LUM) Detection
Cartridges
Item
Detection
cartridge name
Short name
Part number
Weight
Microplate formats 6, 12, 24, 48, 96, 384,
Read mode
Type
Number of slots
Light source
Wavelength range
Labels/Substrates
Detection limit,
Top (ATP)
optimized
Detection limit,
Top (ATP)
guaranteed
Linear dynamic
range, Top
130
Description
Glow Luminescence
(LUM) Detection
Cartridge
LUM
0200-7012
1.5 lbs (0.7 kg)
1536-well microplates
Luminescence (LUM)
Single emission
1 slot, top or bottom,
not in the rear-most
slot
None
Visible to 650 nm
Labels compatible with
the wavelength range
96-well (200 µL)
0.8 fmol/well (4 pM)
384-well (50 µL)
0.35 fmol/well (7 pM)
1536-well (8 µL)
0.32 fmol/well (40 pM)
96-well (200 µL)
2.4 fmol/well (12 pM)
384-well (50 µL)
1.5 fmol/well (30 pM)
1536-well (8 µL)
0.8 fmol/well (100 pM)
5 logs in a single
microplate read
Description
Glow Luminescence
(LUM) Detection Cartridge
(384)
LUM 384
0200-7015
1.5 lbs (0.7 kg)
6, 12, 24, 48, 96, and 384-
well microplates
Luminescence (LUM)
Single emission
1 slot, top or bottom, not
in the rear-most slot
None
Visible to 650 nm
Labels compatible with
the wavelength range
96-well (200 µL)
0.5 fmol/well (2.5 pM)
384-well (50 µL)
0.2 fmol/well (4 pM)
1536-well (8 µL)
NA
96-well (200 µL)
1.4 fmol/well (7 pM)
384-well (50 µL)
0.75 fmol/well (15 pM)
1536-well (8 µL)
NA
5 logs in a single
microplate read
Description
Glow Luminescence
(LUM) Detection
Cartridge (96)
LUM 96
0200-7014
1.5 lbs (0.7 kg)
6, 12, 24, 48, 96-well
microplates
Luminescence (LUM)
Single emission
1 slot, top or bottom, not
in the rear-most slot
None
Visible to 650 nm
Labels compatible with
the wavelength range
96-well (200 µL)
0.3 fmol/well (1.5 pM)
384-well (50 µL)
NA
1536-well (8 µL)
NA
96-well (200 µL)
1.4 fmol/well (7 pM)
384-well (50 µL)
NA
1536-well (8 µL)
NA
5 logs in a single
microplate read
