SpectraMax Paradigm Multi-Mode Detection Platform User Guide
Microplate Recommendations
The following information is specific to this detection cartridge. For general microplate
selection and handling guidelines, see
Table 5-18: Microplate Selection Guidelines for the Fluorescence Intensity Dual Label (FI-
DL) (MultiTox-Fluor) Detection Cartridge
Read Mode
Fluorescence Intensity
(FL), top read
Fluorescence Intensity
(FL), bottom read
Measurement Specifications
The specifications for measurements using the Fluorescence Intensity Dual Label (FI-DL)
(MultiTox-Fluor) Detection Cartridge are shown in the following table.
Table 5-19: Measurement Specification for Fluorescence Intensity Dual Label (FI-DL)
(MultiTox-Fluor) Detection Cartridge
Item
Detection cartridge
name
Short name
Part number
Weight
Read modes
Type
Number of slots
Light source
Filter set
Labels
124
Selecting Suitable Microplate Types on page
Microplate Other Considerations
Type
Solid black When an application specifies a surface treatment, use
only microplates with the correct treatment.
Solid black, When an application specifies a surface treatment, use
clear bottom only microplates with the correct treatment.
Description
Fluorescence Intensity Dual Label (FI-DL) (MultiTox-Fluor) Detection Cartridge
MULTI-TOX
0200-7007
1.5 lbs (0.7 kg)
Fluorescence Intensity (FL)
Fluorescence Resonance Energy Transfer (FRET)
Fluorescence Intensity, Dual Label (FL-Dual)
Dual excitation, dual emission
1 slot, top or bottom
Ultra high power LEDs
EX1: 406-15
EX2: 465-35
EM1:504-12
EM2: 542-27
AFC
R110
MultiTox-Fluor reagents
Other labels compatible with the excitation and emission wavelengths of the
cartridge can also be used.
91.
5014038 E
