Measurement Specifications
The specifications for measurements using the Time Resolved Fluorescence (TRF) Detection
Cartridge are shown in the following table.
Table 5-13: Measurement Specification for Time Resolved Fluorescence (TRF) Detection
Cartridge
Item
Detection cartridge name
Short name
Part number
Weight
Read modes
Type
Number of slots
Light source
Filter set
Labels
Detection limit, Top
optimized
Detection limit, Top
guaranteed
Linear dynamic range, Top
5014038 E
Description
Time Resolved Fluorescence (TRF) Detection Cartridge
TRF-EUSA
0200-0723
1.5 lbs (0.7 kg)
Time-Resolved Fluorescence (TRF)
Time-Resolved Fluorescence, Dual-Label (TRF-Dual)
Dual emission
1 slot, top recommended
Ultra high power LED
EX: 370-80
EM1: 616-10
EM2: 642-10
Europium chelate, Samarium chelate
384-well (100 µL): 3 amol/0.03 pM
1536-well (8 µL): 1 amol/0.125 pM
384-well (100 µL): 10 amol/0.1 pM
1536-well (8 µL): 3 amol/0.375 pM
6 logs in a single microplate read
