Front Panel Controls and Indicators

The front panel of the SpectraMax Paradigm Instrument has LED status indicators that
provide information about instrument status, and a key pad that gives you hardware-based
controls for opening and closing the detection cartridge drawers and the microplate drawer.
To open or close the microplate drawer, press the load/eject button. See
Unloading Microplates on page
To open or close a detection cartridge drawer, press the TOP READ or BOTTOM READ
button. See
2
3
4
Table 4-1: The SpectraMax Paradigm Multi-Mode Detection Platform
Item
1
2
3
4
5
6
7
8
9
80
Using Detection Cartridges on page
1
5
Description
Key pad
Load/eject button for top-read detection cartridge drawer
Load/eject button for microplate drawer
Load/eject button for bottom-read detection cartridge drawer
Status LEDs
Top-read detection cartridge drawer
Microplate drawer
Bottom-read detection cartridge drawer
Standby button
90.
84.
6
7
8
9
Loading and
