Figure 3-8: Power Switch, Fuses, and Connection Ports
Item
1
2
3
4
5
To connect the instrument cables:
1. Make sure that the instrument and host computer are placed on a dry, flat work area
with sufficient space for both devices and the required cables. To ensure sufficient
ventilation and provide access for disconnecting power from the instrument, maintain a
20 cm to 30 cm (7.9 in. to 11.8 in.) gap between the rear of the instrument and the wall.
2. Make sure that the power switch on the rear of the instrument is in the Off position. See
Turning the Instrument On and Off on page
Do not turn on the power to the instrument until after the software has been installed.
3. Turn on the power to the host computer.
5014038 E
Description
USB port
Gas inlet quick-connect fitting
Power switch
Fuse carrier
Power port
Chapter 3: Unpacking and Setting Up the Instrument
1
2
82.
3
4
5
