Figure 4-4: Detection Cartridge Retaining Clips and Retaining Rods
Item
1
2
3
4
5
7. Install more detection cartridges, if desired.
8. Ensure that all the installed cartridges are evenly aligned.
9. Press the TOP READ or BOTTOM READ button on the front panel to close the detection
cartridge drawer.
10. Start the SoftMax Pro Software and connect to the instrument.
If the software is running and connected to the instrument, go to the Operations tab in
the ribbon and click Refresh to let the software detect the installed detection cartridges.
5014038 E
1
4
Description
Detection cartridge
Retaining clip unattached
Retaining clip attached
Retaining rod
Retaining rod
CAUTION! To prevent dust from collecting inside the instrument, the detection
cartridge drawer should be open only for as long as necessary to install or remove
detection cartridges. Keep the detection cartridge drawer closed whenever
possible.
2
3
5
Chapter 4: Using the Instrument
87
