Cleaning the Membrane Holder
To remove dust, buffer residue, and smudges that can have a negative effect on image
quality or contaminate the membrane, always clean the membrane holder before loading a
new membrane for scanning.
The scanning surface can be wiped with methanol, rinsed with a small volume of water,
followed by a final rinse with isopropanol to help prevent blot contamination. Pressurized
"canned air" can be helpful in removing dust and lint.
Adding or Removing Membrane Holder Clips
You can add or remove the holder clips on the membrane holder as needed for your
application.
1. If the clips are in the locked position, then unfasten the clips by pulling up on the tabs.
2. Slide the retainer bar on the "A" column side of the membrane holder out from its slots.
3. Slide the holder clip on or off the end of the retainer bar.
4. Slide the retainer bar into the two slots and press the bar until it snaps into place.
144
Note: When you add a holder clip, make sure that the tab is on top and that the
center of the holder clip curves downward toward the plate.
