Rear Window
Removal
CAUTION: Wear gloves to remove and install the rear
window.
1. To remove the rear window, first remove these
items:
• Seats
• Center pillar trim panel
• Rear upper trim panel
• Rear hatch assembly
2. Remove the weatherstrip.
DEFOGGER SUB-
HARNESS
SPECIAL BOLT
ANTENNA
LEAD
GROUND
CABLE
3. Disconnect the rear defogger sub-harness and
ground cable/antenna lead, then remove the grom-
mets.
Table of Contents
WEATHERSTRIP
GROMMET
4. Remove the rear defogger sub-harness and ground
cable/antenna lead from the upper molding.
REAR DEFOGGER
SUB-HARNESS
5. From outside the vehicle, use a knife to cut the
upper and lower moldings all the way around. Cut
the outer rubber portion
then cut the top rubber portion
CAUTION: Take care not to scratch or score the
rear window and body.
UPPER MOLDING
Replace.
UPPER MOLDING
GROUND CABLE/
ANTENNA LEAD
off the molding first,
REAR WINDOW
LOWER
MOLDING
Replace.
