Status Messages

Status Display

B Channel Status Message Example

The call status can be displayed in a number of ways. The
command on page 4-100 returns a table listing the status,
(deprecated)
speed, and dialed number of current calls.
To display real-time status on individual B channels (incoming or outgoing
calls), either register the API session with the
page 4-30, or start an outbound call with the
These two commands will cause the system to re-direct the B channel status
messages to the session which has issued one of these two commands. For
example, if the RS-232 device issues a dial or listen command, then call
status is directed to the RS-232 port; if a later session on a Telnet port issues a
dial or listen command, then call status is also directed to that Telnet port.
The following output example is for B channel status messages, where:
cs Indicates call status for one B channel.
RINGING Indicates a ring-in or ring-out and is equivalent to a 25% blue
sphere on the graphical user interface.
CONNECTED Is equivalent to a 50% yellow sphere.
BONDING Indicates the bonding protocol is operational on the channel and
is equivalent to a 75% orange sphere.
COMPLETE Is equivalent to a 100% green sphere.
getcallstate
command on
callstate
command on page 4-55.
dial
