Integrator's Reference Manual for Polycom HDX Systems

Vortex Cable

3
2
1
9-POSITION
D-SUBMINIATURE
PLUG
1
6
2
7
3
8
4
9
5
3.5mm PITCH 3-POSITION
PHOENIX PLUG PN 1840379 (8 PL)
1
2
3
PIN #
1 Signal +
2 Signal - (return)
3 Shield/darin wire/ground
2 - 36
This cable connects a Polycom HDX system to a Polycom Vortex mixer. It has
4 mini-Phoenix and DB-9 connectors on both ends.
Length
6 ft (1.8 m)
(203 REF)
P2
P3
P1
P4
P5
4 X 305.0
FROM
P1-2 J1-2
P1-3 J1-3
P1-5 J1-5
P1-7 J1-7
P1-8 J1-8
P1-SHELL J1-SHELL
PINS 1, 4, 6, 9 ARE N/C
P2-1 P6-1
P2-2 P6-2
P2-3 P6-3
P3-1 P7-1
P3-2 P7-2
P3-3 P7-3
P4-1 P8-1
P4-2 P8-2
P4-3 P8-3
P5-1 P9-1
P5-2 P9-2
P5-3 P9-3
Drawings and part numbers are provided for reference only. Polycom claims no responsibility
or liability for the quality, performance, or reliability of cables based on these reference
drawings, other than cables provided by Polycom. Contact your Polycom distributor or
Polycom Custom/Vertical Products to order cables that meet the appropriate manufacturing
tolerances, quality, and performance parameters for your application.
Part Number
2457-21978-200
1829.0 +/- 50
1422.0 (203 REF)
56.0
WRAP LABEL
4 X 203.0
WIRING CHART
TO WIRE TYPE WIRE USE
SIGNAL
SIGNAL
SIGNAL
A
SIGNAL
SIGNAL
SHIELD
SIGNAL
B
SIGNAL
SHIELD (DRAIN WIRE)
SIGNAL
B
SIGNAL
SHIELD (DRAIN WIRE)
SIGNAL
B
SIGNAL
SHIELD (DRAIN WIRE)
SIGNAL
B
SIGNAL
SHIELD (DRAIN WIRE)
RoHS Compliant
Yes
P6
9-POSITION
D-SUBMINIATURE
P7
RECEPTACLE
J1
P8
P9
N/A
5
9
4
8
3
7
2
6
1
