Video and Camera Cables

S-Video Cable

These cables connect a Polycom HDX system to a monitor or camera. They
have yellow 4-pin mini-DIN connectors on both ends and are used with all
Polycom HDX systems. The maximum approved length for this cable is 200 ft
(60 m).
Length
25 ft (7.6 m)
8 ft (2.4 m)
50 ft (15 m)
P3 P4
P1 P2
Drawings and part numbers are provided for reference only. Polycom claims no responsibility
or liability for the quality, performance, or reliability of cables based on these reference
drawings, other than cables provided by Polycom. Contact your Polycom distributor or
Polycom Custom/Vertical Products to order cables that meet the appropriate manufacturing
tolerances, quality, and performance parameters for your application.
Part Number
2457-08409-002
2457-08410-002
2457-09204-200
25 FEET +/- 2"
P1
RoHS Compliant
Yes
Yes
Yes
MINI-DIN MALE 4 POS. ( x2 )
P3 P4
P2
