Page 1 Part No. Z1-004-642, IB019757 Jul. 2018 OPERATION MANUAL DC WITHSTANDING VOLTAGE/ INSULATION RESISTANCE TESTER TOS9200 Series TOS9213S (SPEC80623) TOS9213AS (SPEC80767) DANGER This Tester generates high voltage. Any incorrect handling may cause death. Read Chapter 3 “Precautions on Handling” in this manual to prevent accident.
Page 2 If you find any incorrectly arranged or missing pages in this manual, they will be replaced. If the manual it gets lost or soiled, a new copy can be provided for a fee. In either case, please contact Kikusui distributor/ agent, and provide the “Kikusui Part No.”...
Page 3 Before starting a test, read "6.3 INTERLOCK Connector" for the procedure for starting up the tester using the interlock function. About this manual This operation manual describes the withstanding voltage tester TOS9213S and TOS9213AS. This manual is applicable to the Tester whose ROM version number is: Ver. 1.4x You can check the version number on the opening screen at turning on the power or by using the *IDN? message.
Page 4 • approach to any part connected to the output terminal while the power of the tester is turned • the same action as above immediately after the power of tester has been turned off when in the DC mode of test. TOS9213S/ TOS9213AS...
Page 5 • Use a fuse element having a shape, rating, and characteristics suitable for this product. The use of a fuse with a different rating or one that short circuits the fuse holder may result in fire, electric shock, or irreparable damage. TOS9213S/ TOS9213AS...
Page 6: Safety Symbols
Is placed before the sign “DANGER,” “WARNING,” or “CAU- TION” to emphasize these. When this symbol is marked on the product, see the relevant sections in this manual. Indicates a protective conductor terminal. Indicates a chassis(frame) terminal. iv Safety Symbols TOS9213S/ TOS9213AS...
Page 7: Safety Precautions
• The fuse can be replaced with a new one. When replacing a fuse, use the one which has appropriate shape, ratings, and specifications. Cover • There are parts inside the product which may cause physical hazards. Do not remove the external cover. TOS9213S/ TOS9213AS...
Page 8 • To maintain performance and safe operation of the product, it is recommended that periodic maintenance, checking, cleaning, and calibration be performed. Service • Internal service is to be done by Kikusui service engineers. If the product must be adjusted or repaired, contact Kikusui distributor/agent. TOS9213S/ TOS9213AS...
Page 9 DANGER function, read the Operation Manual. HIGH VOLTAGE terminal For connection, begin with the test To ensure safety, be sure to connect to an earth ground. See “2.5 Connecting the AC Power Cord.” leadwire of the low-voltage level. TOS9213S/ TOS9213AS...
Page 10 This chapter describes the GPIB and RS-232C interfaces and the device messages. Chapter 8 Controlling the TOS6200 This chapter describes the procedure for using the tester to control Kikusui’s earth continuity tester TOS6200 via the RS-232C interface. Chapter 9 Maintenance This chapter describes the maintenance, inspection, and calibration of the tester.
Page 11: Table Of Contents
5.5.3 Settings on the IR3 screen - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-34 Connecting the Test Leadwire- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-36 TOS9213S/ TOS9213AS...
Page 12 Device Messages - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7-10 7.4.1 Register-related messages and general purpose messages - - - - - - 7-10 7.4.2 Messages used exclusively for DC withstanding voltage testing - - - 7-16 TOS9213S/ TOS9213AS...
Page 13 8.1.2 Settings on the TOS6200 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8-2 8.1.3 Settings on the TOS9213S/ TOS9213AS - - - - - - - - - - - - - - - - - - - - 8-3...
Page 14 TOS9213S/ TOS9213AS...
Page 15: Chapter 1 Preface
Chapter 1 Preface This section provides an outline of the tester and explains its features and options. TOS9213S/ TOS9213AS...
Page 16: Outline
Outline The TOS9213S/ TOS9213AS (hereinafter referred to as “the tester”) is withstanding voltage/insulation resistance tester. The tester can perform DC withstanding voltage testing and insulation resistance testing. The tester can operate at up to 10 kVDC (at a maximum output of 50 W for up to 1 minute) in DC withstanding voltage testing.
Page 17 TERMINAL TOS9213S DC WITHSTANDING VOLTAGE/ INSULATION RESISTANCE TESTER terminal Frame RS-232C TOS6200 Example of system application 2 TOS9220/9221 SCAN I/F Maximum of TOS9213S/9213AS 16 channels TERMINAL DC WITHSTANDING VOLTAGE/ TOS9213S INSULATION RESISTANCE TESTER RS-232C TOS6200 GPIB RS-232C TOS9213S/ TOS9213AS...
Page 18: Features
0.01 MΩ to 9.99 GΩ (at rated current range of 50 nA to 1 mA maximum TOS9213S allows you to conduct an insulation resistance test at test voltage range of 25 V to 1000 V (resolution of 1 V) with resistance measuring range of 0.01 MΩ...
Page 19 16 chan- nels. The TOS9221 is equipped with a function for detecting connections between the high-voltage test leadwire and the DUT, thus ensuring highly reliable testing. TOS9213S/ TOS9213AS...
Page 20 LCD, and then turn the rotary knob. The function keys allow you to jump to items to be set. During a test, the output voltage can be changed using the rotary knob. TOS9213S/ TOS9213AS...
Page 21 Around the DUT, provide full safety measures such as an enclosure to keep workers away. In addition, to ensure safety, exercise extreme care to prevent the output of a high voltage due to improper connections and oper- ations. TOS9213S/ TOS9213AS...
Page 22: Options
This switch is used to cut off the output voltage and cancel the FAIL status. It performs the same function as the STOP switch on the front panel. RC01-TOS: RC02-TOS: 200 mm(W) x 70 mm(H) x 39 mm(D) 330 mm(W) x 70 mm(H) x 39 mm(D) TOS9213S/ TOS9213AS...
Page 23 ■ High-voltage test probe HP01A-TOS/HP02A-TOS This test probe is connected to Kikusui’s withstanding voltage tester to output a test voltage. It is designed to prevent the unintended output of a test voltage. To output a test voltage, hold the slide lever on the test-probe grip and pull the trig- ger with one hand, then press the switch on top of the probe using the other hand.
Page 24 • This high-voltage scanner is designed for a maximum working voltage of 5 kVAC/6 kVDC. It is dangerous to apply a voltage exceeding this level. Be sure to use this scanner at a test voltage below the maximum working volt- age. 1-10 TOS9213S/ TOS9213AS...
Page 25: Chapter 2 Setup
Chapter 2 Setup This chapter describes the procedures from unpacking to installation to operation checking. TOS9213S/ TOS9213AS...
Page 26: Unpacking
Upon receiving the product, confirm that the necessary accessories are included and have not been damaged in transit. Should any damage or shortage be found, please contact Kikusui distributor/agent. Retain the packing material for future transport. The power cord that is...
Page 27: Precautions For Installation
■ Do not use the tester in locations affected by strong magnetic or electric fields. Operation in a location subject to magnetic or electric fields may cause the tester to malfunction, resulting in electrical shock or fire. TOS9213S/ TOS9213AS...
Page 28: Precautions For Moving
■ For transportation, use the special packing material for the tester. Transport the tester in its original package to prevent vibration and falls, which may damage the tester. If you require packing material, contact Kikusui distributor/agent. ■ Be sure to include this manual. TOS9213S/ TOS9213AS...
Page 29: Checking The Line Voltage And Fuse
100 VAC to 120 VAC 100 - 120 V (85 VAC to 132 VAC) 47 Hz to 63 Hz 200 VAC to 240 VAC 200 - 240 V (170 VAC to 250 VAC) Fig.2-2 LINE-VOLTAGE RANGE switch TOS9213S/ TOS9213AS...
Page 30: Checking And Replacing Fuses
10 A SLOW – 200 - 240 V – 6.3 A(T) NOTE • The pre-arcing time-current characteristic of fuses are named differently in the UL and IEC standards. Use fuses conforming to both or either of the standards. TOS9213S/ TOS9213AS...
Page 31: Connecting The Ac Power Cord
• If the supplied power cord cannot be used due to the rated voltage or the plug shape, have the cord replaced with an appropriate power cord of length 3 m or less by a qualified engineer. If obtaining a power cord is difficult, consult your Kikusui agent or distributor.
Page 32 Have specialized engineers select, manufacture, and install cables. To ensure secure connection, use proper tools. Electrical ground (safety ground) Fig.2-5 Grounding by using the protective conductor terminal TOS9213S/ TOS9213AS...
Page 33: Checking Operations
See Page 2-10 "Connecting the interlock jumper". Turn on the POWER switch again. Following the opening screen, display the DCW screen and confirm that the tester is kept in the READY status. “READY” flickers on the LCD. The above steps complete the checking procedure. TOS9213S/ TOS9213AS...
Page 34 By lightly pulling on the jumper, confirm that it is connected securely. Take the same steps for the positive (+) and negative (-), then short-cir- cuit both sides. Shank diameter: ø3; tip width: 2.6 mm Fig.2-6 Connecting the jumper 2-10 TOS9213S/ TOS9213AS...
Page 35: Chapter 3 Precautions On Handling
When using the tester, take utmost care to ensure safety. WARNING • The tester derivers a 10 kVDC test voltage which can cause human injury or death. When operating the tester, be extremely careful and observe the cautions, warnings, and other instructions given in this chapter. TOS9213S/ TOS9213AS...
Page 36: Prohibited Operations
You may do either (a) or (b) first. But be sure to do both. (a)Turn OFF the power switch of the tester. (b)Disconnect the AC power cord of the tester from the AC line recep- tacle. TOS9213S/ TOS9213AS...
Page 37: Precautions On Testing
When handling the tester, be sure to wear insulation gloves in order to protect your- self against high voltages. If no insulation gloves are available on your market, please order Kikusui distributor/agent for them. Precautions for Pausing Tests When changing test conditions, press the STOP switch once to take precautions. If you are not going to resume the test soon or if you are leaving the Test area, be sure to turn-OFF the POWER switch.
Page 38: Warning For Residual High Voltages
The length of the discharge time varies according to the properties of the DUT and the test voltage. Discharge is conducted at a resistance of approximately 500 kΩ in DC withstanding voltage testing, and at 25 kΩ in insulation resistance testing. TOS9213S/ TOS9213AS...
Page 39: Dangerous States Of Failed Tester
Never use the tester when it has failed. WARNING • Keep the tester away of other people until you call our service engineer for help. • Immediately call Kikusui distributor/agent. It is hazardous for an unquali- fied person to attempt to troubleshoot any tester problem. TOS9213S/ TOS9213AS...
Page 40: To Ensure Long-Term Use Without Failures
• The coating of the high-voltage test leadwire is free from cracks, fissures, and breakage. • The high-voltage test leadwire is not broken. • The tester generates FAIL signal when the ends of the low-voltage test lead- wire and high-voltage test leadwire are short-circuited. TOS9213S/ TOS9213AS...
Page 41: Chapter 4 Part Names And Functions
Chapter 4 Part names and Functions This chapter describes the names and functions of components such as switches, displays, and connectors on the front and rear panels. TOS9213S/ TOS9213AS...
Page 42: Front Panel
The test starts when this switch is pressed while “READY” is displayed on the LCD. Once the test starts, the LCD displays “TEST” and the TEST LED flashes on the indicator during a voltage rise. When the tester reaches the test voltage, the TEST LED remains lit. TOS9213S/ TOS9213AS...
Page 43 (IR). • SYSTEM /I/F When this key is pressed, the LED lights up. The LCD displays the system set- tings screen (SYSTEM). To display the interface settings screen (INTERFACE), press this key together with the SHIFT key. TOS9213S/ TOS9213AS...
Page 44 Red lamp indicating that a high voltage is being output. This lamp lights up during testing and automatic testing, or while an output voltage remains in the output terminal. WARNING • While this lamp is lit, never touch the HIGH VOLTAGE terminal, test lead- wire, or DUT. TOS9213S/ TOS9213AS...
Page 45: Basic Operations
When pressed together with the SHIFT key, it enables screen contrast adjustment and the switching of setting screens. [17] Rotary knob READY status : Used to set test conditions on the LCD Test in Progress : Used to change the test voltage TOS9213S/ TOS9213AS...
Page 46: Rear Panel
Connector used to connect an RS-232C cable in order to remotely control the tester via a PC using the RS-232C interface. [20] STATUS OUT Connector for connecting a warning light. Maximum output voltage of 24 VDC and maximum output current of 100 mA. TOS9213S/ TOS9213AS...
Page 47 Power-cord connector used to supply power to the tester. Use the power cord pro- vided with the product. WARNING • Improper handling of this connector may lead to electric shock. Be sure to follow the instructions given in "2.5 Connecting the AC Power Cord". TOS9213S/ TOS9213AS...
Page 48 For details, see "2.5 Connecting the AC Power Cord". [29] Cord holder Holder for the power cord. CAUTION • Do not place the tester on sides other than the bottom surface. Leaving the cord holder beneath the tester makes it extremely unstable, and is extremely dangerous. TOS9213S/ TOS9213AS...
Page 49: Chapter 5 Basic Operations
Chapter 5 Basic Operations This chapter describes the procedures for conducting withstanding voltage and insu- lation resistance tests. TOS9213S/ TOS9213AS...
Page 50: Turning On The Power
LCD displays the last screen displayed when the POWER switch was turned off in the previous test. The first time the POWER switch is turned on following the delivery of the product, the tester is placed in the PROTEC- TION status by the interlock function. TOS9213S/ TOS9213AS...
Page 51: Pre-Test Zero Adjustment
Before starting a test, perform zero adjustment on the analog voltmeter. Perform the following procedure: Turn off the POWER switch. Confirm that the analog voltmeter indicates “0.” Otherwise, adjust the analog-voltage zero adjuster until the voltmeter indicates “0.” Analog voltmeter zero adjuster OUTPUT DANGER HIGH VOLTAGE MAX 10kV TERMINAL TOS9213S/ TOS9213AS...
Page 52: Structure Of Lcd Screen
(DC Withstanding Voltage Test) screen Page 3 Page 2 Page 1 (Insulation Resistnce Test) Page 4 Page 3 Page 2 Page 1 SYSTEM AUTO EDIT INTERFACE Execution DCW TEST screen IR TEST AUTO TEST Fig.5-1 Structure of the LCD screen TOS9213S/ TOS9213AS...
Page 53: Settings For Dc Withstanding Voltage Testing
When a function is shown on the F1 to F5 keys, they can be used to jump to the tar- get item. To make settings for items displayed on these keys, press the SHIFT key + F1 to F5 keys. TOS9213S/ TOS9213AS...
Page 54: Settings On The Dcw1 Screen
ON and OFF alternate. keys can also be used to move the cursor to ON/OFF of the lower judgement function. If the cursor is at ON/OFF of the lower judgement function, the rotary knob can be used to make settings. TOS9213S/ TOS9213AS...
Page 55 LCD to indicate that testing cannot be performed (the lower reference is factory-set to 0.10 mA). Lower the lower reference or raise the upper reference. • No lower judgement is made while the voltage is rising or before the WAIT TIME has elapsed. TOS9213S/ TOS9213AS...
Page 56 • When settings are being made, if the test voltage multiplied by the upper reference exceeds 55 W, “READY” disappears and “OVER 55 W” flashes at the top right of the LCD to indicate that testing cannot be performed. In such a case, lower the test voltage or the upper reference. TOS9213S/ TOS9213AS...
Page 57 When the cursor is at the timer, the rotary knob can be used to make settings. To move the cursor to the timer, press the F5 key (TIMER). (The keys can also be used.) Using the keys, move the cursor to the target digit. Using the rotary knob, set the test time. TOS9213S/ TOS9213AS...
Page 58: Settings On The Dcw2 Screen
The rise time between the start voltage and the test voltage can be set to 0.1 s through 200 s (at a resolution of 0.1 s for the 0.1 s to 99.9s range and 1 s for the 100 s to 200s range). 5-10 TOS9213S/ TOS9213AS...
Page 59 • Discharging will stop if you press the STOP switch during forced discharge. How- ever, discharging will not stop if the discharge time has been set to 0.0 s. WARNING • When you stop forced discharge, the voltage between the output terminals may still be at a dangerous level. TOS9213S/ TOS9213AS 5-11...
Page 60 The current detection response can be set using the SHIFT + F2 keys (RESPONSE), regardless of the location of the cursor. Each time the SHIFT + F2 keys are pressed, the selection is switched among SLOW, MID, and FAST, in order. 5-12 TOS9213S/ TOS9213AS...
Page 61 Corona discharge or instanta- neous flashover is not regarded as dielectric breakdown.” In accordance with this standard, Kikusui’s withstanding voltage tester makes a FAIL judgement for a test if the tester, having a mean-value-responsive current-detection circuit, detects a current above the upper reference (UPPER) flowing into a DUT.
Page 62 Turn the rotary knob clockwise: GUARD Turn the rotary knob counterclockwise: LOW When LOW is selected, the LOW/GUARD LED lights up. LOW/GUARD LED lights up OUTPUT DANGER HIGH VOLTAGE MAX 10kV TERMINAL 5-14 TOS9213S/ TOS9213AS...
Page 63 Ammeter terminal TOS9213S TOS9213AS Setting to LOW (A) DUT grounded HIGH VOLTAGE terminal Insulation resistance of test lead wire and jigs Ammeter terminal TOS9213S TOS9213AS Setting to LOW (B) DUT not grounded Fig.5-3 Selecting LOW TOS9213S/ TOS9213AS 5-15...
Page 64 TOS6200, the ammeter will make mea- surement errors if GUARD is selected, as the resistor inside the TOS6200 is connected in parallel to the tester’s ammeter. Therefore, to use the TOS6200, avoid connecting these terminals, or select LOW. 5-16 TOS9213S/ TOS9213AS...
Page 65 HIGH VOLTAGE terminal Insulation resistance of the test lead wire and jigs Ammeter terminal TOS9213S TOS9213AS Setting to GUARD Fig.5-5 Selecting GUARD TOS9213S/ TOS9213AS 5-17...
Page 66: Settings On The Dcw3 Screen
INVALID CH DCW3 DCW3 CONTACT CHECK : ON 1 1 1 1 1 1 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 HIGH : LOW : HIGH OPEN 5-18 TOS9213S/ TOS9213AS...
Page 67 When a continuity error is detected in a contact check, “ →← FAIL” appears at the top right of the LCD. On the high-voltage scanner, the LED of the failed channel lights up in orange. →← FAIL DCW1 DCW1 LOWER TIMER UPPER 1.00 5.00 – VOLT LOWER UPPER TIMER TOS9213S/ TOS9213AS 5-19...
Page 68: Settings For Insulation Resistance Testing
When a function is shown on the F1 to F5 keys, they can be used to jump to the tar- get item. To conduct the operations displayed on these keys, press the SHIFT key + the F1 to F5 keys. 5-20 TOS9213S/ TOS9213AS...
Page 69: Settings On The Ir1 Screen
The test voltage to be applied to a DUT can be set to -10 V through -1020 VDC (at a resolution of 1 V) on TOS9213S, and -10 V through -1530 V(at resolution of 1V) on TOS9213AS. (The negative (-) mark is not displayed.) To make setting, use the rotary knob with the cursor at the test voltage.
Page 70 "Selecting Resistance Value-based or Current Value-based Judgement" on page 5-26. Resistance value-based judgment Current value-based judgment READY READY LOWER UPPER TIMER LOWER UPPER TIMER 0.01 − − µA LOWER LOWER VOLT LOWER UPPER TIMER VOLT LOWER UPPER TIMER SHIFT SHIFT 5-22 TOS9213S/ TOS9213AS...
Page 71 ±(10% of the setting + 50 V), the measured voltage flashes on the LCD voltmeter to warn of a decrease in the test voltage. The test can still be conducted, however. TOS9213S/ TOS9213AS 5-23...
Page 72 "Selecting Resistance Value-based or Current Value-based Judgement" on page 5-26. Resistance value-based judgment Current value-based judgment READY READY LOWER UPPER TIMER LOWER UPPER TIMER UPPER 10.0 UPPER − − µA VOLT LOWER UPPER TIMER VOLT LOWER UPPER TIMER SHIFT SHIFT 5-24 TOS9213S/ TOS9213AS...
Page 73 “READY” disappears and “UP<=LOW” flashes at the top right of the LCD to indicate that testing cannot be performed. Raise the upper reference, reduce the lower reference, or turn off the lower judge- ment function. TOS9213S/ TOS9213AS 5-25...
Page 74 ON/OFF of the timer function. If the cursor is at ON/OFF of the timer function, the rotary knob can be used to make settings. Turn the rotary knob clockwise : ON Turn the rotary knob counterclockwise : OFF 5-26 TOS9213S/ TOS9213AS...
Page 75 When the cursor is at TIMER, the rotary knob can be used to make settings. To move the cursor to TIMER, press the F5 key (TIMER). (The keys can also be used.) Using the keys, move the cursor to the target digit. Using the rotary knob, set the test time. TOS9213S/ TOS9213AS 5-27...
Page 76: Settings On The Ir2 Screen
When the cursor is to the right of DISCH, settings can be made using the rotary knob. To move the cursor to the right of DISCH, press the F3 key (DISCH). (The keys can also be used.) Using the rotary knob, set the rise time. 5-28 TOS9213S/ TOS9213AS...
Page 77 NOTE • With the timer ON, if the wait time thus set exceeds the sum of the voltage rise time and the test time, “OVER WAIT” flashes on the LCD to indicate that testing cannot be performed. TOS9213S/ TOS9213AS 5-29...
Page 78 Turn the rotary knob clockwise : GUARD Turn the rotary knob counterclockwise : LOW When LOW is selected, the LOW/GUARD LED lights up. LOW/GUARD LED lights up OUTPUT DANGER HIGH VOLTAGE MAX 10kV TERMINAL 5-30 TOS9213S/ TOS9213AS...
Page 79 Ammeter terminal TOS9213S TOS9213AS Setting to LOW (A) DUT grounded HIGH VOLTAGE terminal Insulation resistance of the test lead wire and jigs Ammeter terminal TOS9213S TOS9213AS Setting to LOW (B) DUT not grounded Fig.5-7 Selecting LOW TOS9213S/ TOS9213AS 5-31...
Page 80 TOS6200, the ammeter will make mea- surement errors if GUARD is selected, as the resistor inside the TOS6200 is connected in parallel to the tester’s ammeter. Therefore, to use the TOS6200, avoid connecting these terminals, or select LOW. 5-32 TOS9213S/ TOS9213AS...
Page 81 As shown in Fig. 5-9, the GUARD mode enables high-sensitivity, high accuracy measurement, as it excludes the insulation resistance of the test leadwire and jigs. HIGH VOLTAGE terminal Insulation resistance of the test lead wire and jigs Ammeter terminal TOS9213S TOS9213AS Setting to GUARD Fig.5-9 Selecting GUARD TOS9213S/ TOS9213AS 5-33...
Page 82: Settings On The Ir3 Screen
• If an unconnected channel is selected, “INVALID CH” flashes on the LCD. INVALID CH CONTACT CHECK : ON 1 1 1 1 1 1 1 1 2 3 4 5 6 7 8 3 4 5 6 9 0 1 2 HIGH : LOW : HIGH OPEN 5-34 TOS9213S/ TOS9213AS...
Page 83 When a continuity error is detected in a contact check, “ →← FAIL” appears at the top right of the LCD. On the high-voltage scanner, the LED of the failed channel lights up in orange. →← FAIL LOWER UPPER TIMER 0.01 − LOWER VOLT LOWER UPPER TIMER TOS9213S/ TOS9213AS 5-35...
Page 84: Connecting The Test Leadwire
Short-circuit the low-voltage and high-voltage test leadwires, and con- firm that no high voltage is output. 5.6.2 Connecting a DUT After connecting the low-voltage and high-voltage test leadwires, connect a DUT by following the procedure specified below. Press the STOP switch. 5-36 TOS9213S/ TOS9213AS...
Page 85 Location as close as possible to the DUT 470 , 3 W HIGH VOLTAGE terminal LOW terminal 470 , 3 W TOS9213S TOS9213AS Location as close as possible to the DUT Fig.5-12 Reducing the effects of noise TOS9213S/ TOS9213AS 5-37...
Page 86: Starting And Ending A Test
The time is displayed differently depending on whether the timer function is on or off. The timer is ON : The remaining test time is displayed. The timer is OFF : The elapsed test time is displayed. (When 999 seconds have elapsed, “999” flashes.) 5-38 TOS9213S/ TOS9213AS...
Page 87 1.1 mA, testing can be performed. However, when the voltage value which is out of the range of ±(10 % of setting +50 V) is detected during the test, the measurement voltage value flashes on the LCD. TOS9213S/ TOS9213AS 5-39...
Page 88: Ending The Test
READY status after a PASS judgement is made. When the timer is OFF: The test continues until the FAIL conditions are met. Press the STOP switch to suspend the test. The test does not make a judgement and “PASS” is not displayed. 5-40 TOS9213S/ TOS9213AS...
Page 89 • In DC withstanding voltage testing, no lower judgement is made during a voltage rise time (RISE TIME). • In DC withstanding voltage testing, an upper judgement is not made until the WAIT TIME has elapsed to eliminate the effects of a charge current in capacitive DUTs. TOS9213S/ TOS9213AS 5-41...
Page 90 TIME has elapsed to eliminate the effects of a charge current in capacitive DUTs. START START HV ON HV ON TEST TEST Output voltage Output voltage FAIL FAIL STOP STOP READY READY Fig.5-14 Timing chart for the FAIL judgement 5-42 TOS9213S/ TOS9213AS...
Page 91: System Settings
A leakage-current measurement mode can be selected. NORM : Ordinary measurement mode MIN/MAX : The measurement mode for holding the maximum current in withstanding voltage testing and the minimum resistance recorded after the WAIT TIME has elapsed in insulation resis- tance testing TOS9213S/ TOS9213AS 5-43...
Page 92 Turn the rotary knob counterclockwise : OFF When ON is set, items are highlighted. SYSTEM 1 SYSTEM 1 MEAS MODE : NORM MOMENTARY PASS HOLD : 10.0s FAIL MODE DOUBLE ACTION MOMEN FAIL DOUBLE TARY MODE ACTION SHIFT 5-44 TOS9213S/ TOS9213AS...
Page 93: System2
DOUBLE ACTION, settings can be made using the rotary knob. Turn the rotary knob clockwise : ON Turn the rotary knob counterclockwise : OFF 5.8.2 SYSTEM2 SYSTEM 2 SYSTEM 2 BUZZER VOL. CONTRAST DISCH MODE NORM BUZZER CONTRAST DISCH TOS9213S/ TOS9213AS 5-45...
Page 94 Using the F3 key (DISCH) or the keys, move the cursor to DISCH MODE. Using the rotary knob, adjust the discharge mode. The discharge mode can be set using the SHIFT + keys, regardless of the screen displayed. 5-46 TOS9213S/ TOS9213AS...
Page 95: System3
When L FAIL is set to ON, 24 VDC is output while FAIL is output in a lower judgement. C FAIL When C FAIL is set to ON, 24 VDC is output while FAIL is output in a contact check. TOS9213S/ TOS9213AS 5-47...
Page 96: System4
A comment can be added using up to 3 lines with 20 characters per line (ASCII 20H to 7EH, Appendix 2). Display the SYSTEM4 screen. Using the keys, move the cursor to where the comment is to be input. Using the rotary knob, select characters. 5-48 TOS9213S/ TOS9213AS...
Page 97: Interface Settings
5. Stop bit of the RS-232C interface INTERFACE INTERFACE GPIB ADDRESS : 3 SPEED : 19200 PARITY : NONE DATA : 8bit STOP : 2bit GPIB SPEED DATA PARITY STOP For each interface setting, see "7.1 GPIB Interface" or "7.2 RS-232C Interface". TOS9213S/ TOS9213AS 5-49...
Page 98: 5.10 Panel Memory
Storing the results of an DC withstanding voltage test in panel memory (example) Press the DCW key to display the DC withstanding voltage test screen (DCW1), and set the test conditions. 5-50 TOS9213S/ TOS9213AS...
Page 99: 2Recalling Panel Memory
To cancel the recall operation, move the cursor to any location on the display before pressing the ENTER key. Once the recalled test conditions have been changed, the memory number disappears. The memory number does not reappear even if the pre- vious test conditions are restored. TOS9213S/ TOS9213AS 5-51...
Page 100: 5.11 Program
HOLD. Thus, Step 01 does not start until the START switch is pressed. When START is pressed, IR01 (insulation resistance test) ends at Step 01 and, 0.5 seconds later, the tester enters the READY status. When END is set to RET, the test restarts at Step 00. 5-52 TOS9213S/ TOS9213AS...
Page 101: 1Creating And Editing A Program
Using the rotary knob, select characters. Use ASCII characters from 20H (space) to 7EH (~) (see the Appendix"A.2 ASCII Code 20H to 7EH"). Upon completion of editing, press the SHIFT + F1 keys to move the cur- sor to the step number. TOS9213S/ TOS9213AS 5-53...
Page 102 To delete a step, move the cursor to the corresponding step number and press the F2 key (DEL). To change the interval time or the memory number of a step, move the cursor to the target and make changes using the rotary knob. 5-54 TOS9213S/ TOS9213AS...
Page 103: 2Executing A Program
• If the test executes a step with the timer function set to OFF, it is unable to proceed to the next step. To run a program, display the program screen (AUTO). TEST AUTO AUTO 05 : KIKUSUI 01 DCW00-0.2s 02 IR 00-0.2s NAME : --UNTITLED-- ▼...
Page 104: 4Judgement On The Program
5.11.5 Exiting the program To exit the PROGRAM mode in order to return to the normal mode, press the DCW key or IR key. The LED on the AUTO key goes off, and the test-condition setting screen appears. 5-56 TOS9213S/ TOS9213AS...
Page 105: 5.12 Key Lock
“OVER 0.11 mA” is displayed when the test voltage divided by the only) lower/upper reference exceeds 0.11 mA. UP<=LOW “UP<=LOW” is displayed when, with the lower or upper judgement function on, the upper value is set at or below the lower value. TOS9213S/ TOS9213AS 5-57...
Page 106: 5.14 Protection
When the main power supply in the tester is overloaded, “OVER CURR” flashes on the LCD. Press the POWER-switch again. If “OVER CURR” is still displayed, an internal cir- cuit may be broken. Contact Kikusui distributor/agent. OVER CURR DCW1 DCW1...
Page 107 In this case, the measured voltage flashes on the LCD voltmeter to indicate the decrease in the test voltage if the output voltage deviates the monitor range. VOLT ERROR DCW1 DCW1 LOWER TIMER UPPER 1.00 5.00 VOLT LOWER UPPER TIMER TOS9213S/ TOS9213AS 5-59...
Page 108 “24V OCP” flashes on the LCD. To cancel the protection function, eliminate the cause of the problem and then press the STOP switch. 24V OCP DCW1 DCW1 LOWER TIMER UPPER 1.00 5.00 VOLT LOWER UPPER TIMER 5-60 TOS9213S/ TOS9213AS...
Page 109 TOS6200, “COM ERR” flashes on the LCD. To cancel the protection function, eliminate the cause of the communication error and then press the STOP switch. COM ERR AUTO AUTO 00 : --UNTITLED-- 01 DCW 00-1.0s 02 IR 02-1.0s 03 EC 03-1.0s TOS9213S/ TOS9213AS 5-61...
Page 110: 5.15 Initialization
To initialize the tester, press the SHIFT key + the POWER switch to start it up. Ini- tialization will start. All contents of memory are deleted, and the tester returns to the factory settings. (Hold the SHIFT key down until “KIKUSUI ELECTRONICS CORP.” disappears.)
Page 111: Chapter 6 Using Terminals And Connectors
While a high voltage is being generated, the DUT, high-voltage test leadwire, probe, and output terminals never touched. Never conduct remote control unless sufficient safety measures have been provided. TOS9213S/ TOS9213AS...
Page 112: Remote Terminal
5 kVDC or less. CAUTION • Keep the signal line at least 500 mm from the high-voltage test leadwire and the DUT. Do not short-circuit the test voltage to the signal line. Other- wise, all internal circuits may be destroyed. TOS9213S/ TOS9213AS...
Page 113 • In making system settings, when FAIL MODE is set to ON, the FAIL or PRO- TECTION status cannot be cancelled even if the STOP signal is input from the REMOTE terminal. To cancel the statuses, press the STOP switch on the panel. For the system settings, see "5.8 System Settings". TOS9213S/ TOS9213AS...
Page 114: Signal I/O Connector
Connect them to the tester’s housing (do not connect the COM line to a shield or an earth ground). These measures insulate SIGNAL I/O-related circuits from the external environment, thus reduc- ing malfunction due to noise. TOS9213S/ TOS9213AS...
Page 115: Specifications For The Signal I/O Connector
Output signal 1 Output- signal control Output signal 2 block • • +12V • Input signal 1 Input- +12V signal control block Input signal 2 • • • Fig.6-4 Internal configuration of the SIGNAL I/O block TOS9213S/ TOS9213AS...
Page 116 100 mA Circuit common (chassis potential) NOTE • If U FAIL and L FAIL are turned on simultaneously, CONTACT FAIL is meant. • It is impossible to directly control the input signal using a logic IC such as HC. TOS9213S/ TOS9213AS...
Page 117: Example
400 mA or less 30 V or less Achieving the L-level for the digital signal (example) Using the output signal, the L-level for the digital signal can be achieved. 30 V or less “L” during signal output TOS9213S/ TOS9213AS...
Page 118: Starting A Test
At the same time, the START input for the REMOTE terminal and the START switch on the panel are disabled. ENABLE (IN) READY (OUT) 5 ms or more START (IN) 10 ms or more Fig.6-5 START signal TOS9213S/ TOS9213AS...
Page 119 To cancel these statuses, use the STOP switch on the panel. For the system settings, see "5.8 System Settings". • The input terminal is pulled up to +12 V by resistance. Opening the input terminal is equivalent to inputting a high level. TOS9213S/ TOS9213AS...
Page 120: Recalling The Panel Memory And Programs
The next signal input requires an interval of 10 ms or more. Fig.6-6 Strobe signal NOTE • The input terminal is pulled up to +12 V by resistance. Opening the input terminal is equivalent to inputting a high level. 6-10 TOS9213S/ TOS9213AS...
Page 121 Recalls AUTO program 2. • • • • • • • • • • • • • • • • • • • • • • • • • • • Recalls AUTO program 98. Recalls AUTO program 99. TOS9213S/ TOS9213AS 6-11...
Page 122: Interlock Connector
Circuit of the interlock input block +12 V Door open/close switch – 3.3 k 5.6 V INTERLOCK Internal circuit of TOS9213S/ TOS9213AS 6-12 TOS9213S/ TOS9213AS...
Page 123 • 30 VDC, 0.1 A or more Circuit for reference When the door is opened, its contacts open, thus setting the INTERLOCK signal high. This activates the interlock function. Door open/close switch Connection to the door open/close switch TOS9213S/ TOS9213AS 6-13...
Page 124: Status Out Connector
OCP” flashes on the LCD. The tester enters the PROTECTION status. If the overcurrent protection function activates, turn off the POWER switch to prevent an overcurrent. If an overcurrent flows for an extended period, the internal circuit may mal- function. 6-14 TOS9213S/ TOS9213AS...
Page 125: Chapter 7 Gpib/Rs-232C Interface
GPIB or RS-232C interface, the tester returns PROTECTION (line voltage monitoring) message. However, when the power of the tester is turned on while an abnormal voltage occurs already on the power line, the tester cannot return a message. TOS9213S/ TOS9213AS...
Page 126: Gpib Interface
GPIB system. Connect the GPIB cable to the GPIB connector on the rear panel of the tester. GPIB cables are available from Kikusui. Contact the supplier or your Kikusui agent. GPIB cable: 1 m (Product No. 92080) GPIB cable: 2 m (Product No. 92070) GPIB cable: 4 m (Product No.
Page 127: Setting The Gpib Address
1. Using the F1 key (GPIB) or the keys, move the cursor to the GPIB ADDRESS. 2. Using the rotary knob, set a GPIB address. 3. On the tester, turn off the POWER switch and then turn it on again. TOS9213S/ TOS9213AS...
Page 128: Rs-232C Interface
INTERFACE GPIB ADDRESS : 4 SPEED : 19200 PARITY : NONE DATA : 8bit STOP : 2bit GPIB SPEED DATA PARITY STOP NOTE • When the interface settings are changed, they become valid after the tester is restarted. TOS9213S/ TOS9213AS...
Page 129 • NONE • ODD • EVEN Setting the stop bit Using the F5 key (STOP) or the keys, move the cursor to STOP. Using the rotary knob, select either of the following: • 1 bit • 2 bits TOS9213S/ TOS9213AS...
Page 130: Rs-232C Flow Control
Controlling transmission from the tester to the RS-232C terminal Suspend Restart transmission Up to ten characters Have the RS-232C terminal suspend transmission within 10 characters following the receipt of DC3. Fig.7-2 Controlling transmission between the RS-232C terminal and the tester TOS9213S/ TOS9213AS...
Page 131: Messages And Terminators
Program messages are either “command messages” or “query messages.” Command messages are used to execute specific functions of the tester and to change settings. Query messages are used to inquire about the settings and status of the tester. TOS9213S/ TOS9213AS...
Page 132 ASCII codes. The following two acknowledge messages are used: • OK : Normal termination • ERROR : Abnormality such as a syntax error Using the SILENT command message, settings can be made to specify whether to return an acknowledge message. TOS9213S/ TOS9213AS...
Page 133: Terminators
The parentheses indicate program data. In actual program- < > ming, do not use these parentheses. Choose one from among the characters and numerals enclosed in parentheses and separated by “ | ”. In actual pro- gramming, do not use these parentheses. Represents a space TOS9213S/ TOS9213AS...
Page 134: Device Messages
(Example) When Bit 5 of the event status register is set, 32 is returned. *IDN Inquires about the model name and ROM version of the tester Message *IDN? Query: Response The model name of the tester is returned to *IDN?, as follows: 7-10 TOS9213S/ TOS9213AS...
Page 135 KIKUSUI ELECTRONICS CORP., TOS9213S, 0, 1.40 Company name Model name Version No. Not used *RST Initializes the tester (to original factory-set settings). Note the settings made in the INTERFACE screen will not be initialized. For details on initialization, see "5.15 Initialization".
Page 136 (Example) When Bit 5 of the device-status enable register is set, 32 is returned. The error register is reset when read by the ERR? Message. For details on the error register, see "7.5 Registers". Message ERR? Query: 7-12 TOS9213S/ TOS9213AS...
Page 137 For details on the invalid-setting register, see "7.5 Registers". Message INVALID? Query: INV? Response To INV?, the contents of the invalid-setting register are returned. (Example) When Bit 3 of the invalid-setting register is set, 8 is returned. TOS9213S/ TOS9213AS 7-13...
Page 138 Message Setting: SILENT_<{0|1}> SIL_<{0|1}> SILENT? Query: SIL? Program data Data format: Integer Set value: 0: Return an acknowledge message. 1: Do not return an acknowledge message. (Example) To set “Do not return an acknowledge message,” SIL 1 7-14 TOS9213S/ TOS9213AS...
Page 139 0: CR/LF+EOI; 1: LF+EOI; 2: EOI; 3: CR+EOI (Example) To set the response-message terminator to LF+EOI, TRM 1 Response To TRM?, the preset response-message terminator is returned. (Example) If the response-message terminator is set to LF+EOI, 1 is returned. TOS9213S/ TOS9213AS 7-15...
Page 140: Messages Used Exclusively For Dc Withstanding Voltage Testing
DC withstanding voltage test. Also inquires about the lower reference and the ON/ OFF status of the lower judgment function. Message Setting: DCW:LOWER_<lower reference, {ON|OFF}> D:LOW_<lower reference, {ON|OFF}> DCW:LOWER? Query: D:LOW? <lower reference> Program data Data format: Real number Set value: 0.01 E-3 to 5.50 E-3 7-16 TOS9213S/ TOS9213AS...
Page 141 0.999 E-3 Unit: (Example) To set the upper reference to 5 mA, A:UPP 5E-3 Response To D:UPP?, the preset upper reference is returned. (Example) If the upper reference is currently set to 2.00 mA, 2.00E-3 is returned. TOS9213S/ TOS9213AS 7-17...
Page 142 Unit: (Example) To set the start voltage to 10% of the test voltage, D:STAR 10 Response To D:STAR?, the current start voltage is returned. (Example) If the start voltage is currently set to 0%, 0 is returned. 7-18 TOS9213S/ TOS9213AS...
Page 143 0.1 for 0.5 to 99.9, 1 for 100 to 300 Unit: (Example) To set the discharge time to 1 s, D:DIS 1 Response To D:DIS?, the current discharge time is returned. (Example) If the discharge time is currently set to 2.0 s, 2.0 is returned. TOS9213S/ TOS9213AS 7-19...
Page 144 (Example) To set the current detection response speed to FAST, D:RES 2 Response To D:RES?, the preset current detection response speed is returned. (Example) If the detection response speed is currently set to MID, 1 is returned. 7-20 TOS9213S/ TOS9213AS...
Page 145 (B). • When GUARD is selected, do not connect the tester to devices grounded on a single side, such as Kikusui’s high-voltage digital voltmeter 149-10A or current calibrator TOS1200. Otherwise, the ammeter will be short-cir- cuited. See Fig. 7-4 (A).
Page 146 Sets HIGH/LOW/OPEN for 16 scanner channels at a time using 16 bits in a DC withstanding voltage test. Also inquires about the current settings for all 16 channels. Message Setting: DCW:SCANW_<setting 1, setting 2> D:SCANW_<setting 1, setting 2> 7-22 TOS9213S/ TOS9213AS...
Page 147 OFF (0), ON (1) (Example) To set the contact check to ON, D:CCH ON Response To D:CCH?, the current setting for the contact check is returned. (Example) If the contact check is currently set to ON, 1 is returned. TOS9213S/ TOS9213AS 7-23...
Page 148: Messages Used Exclusively For Insulation Resistance Testing
I:TES_<voltage> IR:TESTV? Query: I:TES? Program data Data format: Integer Set value: 10 to 1020 (TOS9213S) 10 to 1530 (TOS9213AS) Resolution: Unit: (Example) To set the test voltage to 500 V, I:TES 500 Response To I:TES?, the currently set test voltage is returned.
Page 149 To I:LOW?, the currently set lower reference and the ON/OFF status of the lower judgment function are returned as “lower reference, 1/0.” (Example) If the lower reference is currently set to 1.00 GΩ and the lower judg- ment function to OFF, “1.00E9,0” is returned. TOS9213S/ TOS9213AS 7-25...
Page 150 To I:UPP?, the preset upper reference and the ON/OFF status of the upper judgment function are returned as “upper reference, 1/0.” (Example) If the upper reference is currently set to 5.00 GΩ and the upper judg- ment function to OFF, “5.00E9,0” is returned. 7-26 TOS9213S/ TOS9213AS...
Page 151 Response To I:IJUD?, a value indicating whether or not current value judgement is enabled is returned. (Example) If current value judgement is enabled, 1 is returned. NOTE • I:IJUD ON and I:RJUD OFF are the same setting. TOS9213S/ TOS9213AS 7-27...
Page 152 (Example) To set the voltage rise time to 1 s, I:RTIM 1 Response To I:RTIM?, the current voltage rise time is returned. (Example) If the voltage rise time is currently set to 2.0 s, 2.0 is returned. 7-28 TOS9213S/ TOS9213AS...
Page 153 Resolution: Unit: (Example) To set the WAIT TIME to 1 s, I:WTIM 1 Response To I:WTIM?, the currently set WAIT TIME is returned. (Example) If the WAIT TIME is currently set to 2.0 s, 2.0 is returned. TOS9213S/ TOS9213AS 7-29...
Page 154 See Fig. 7-5 (B). • When GUARD is selected, do not connect the tester to devices grounded on a single side, such as Kikusui’s high-voltage digital voltmeter 149-10A or current calibrator TOS1200. Otherwise, the ammeter will be short-cir- cuited.
Page 155 O (0): OPEN; L (1): LOW; H (2): HIGH (Example) To set scanner channel 1 to HIGH, I:SCAN 1,H Response To I:SCAN? 2, the scanner channel 2 setting is returned. (Example) If the scanner channel is currently set to OPEN, 0 is returned. TOS9213S/ TOS9213AS 7-31...
Page 156 I:CCH_<{ON|OFF}> IR:CONTACTCHECK? Query: I:CCH? Program data Data format: Character Set value: OFF (0), ON (1) (Example) To set the contact check to ON, I:CCH ON Response To I:CCH?, the current setting for the contact check is returned. 7-32 TOS9213S/ TOS9213AS...
Page 157: Messages Common To All Tests
Message IDATA? Query: IDAT? Response To IDAT?, the monitor current is returned for DCW in a DC withstanding voltage test. (Example) If the present monitor current in an DC withstanding voltage test is 10.0 10.0E-3 is returned. TOS9213S/ TOS9213AS 7-33...
Page 158 When no test is under way, the previous test results are returned. Returning in DC withstanding voltage testing Test type (1: DCW), monitor voltage, monitor current NORM, monitor current MAX, monitor resistance MIN, elapsed (remaining) time, test status (0: Rise/1: Test/3: End) 7-34 TOS9213S/ TOS9213AS...
Page 159 Inquires about the channel in the C FAIL status. Message CFAILCH? Query: CFCH? Response To CFCH?, the channel in the CONTACT FAIL status is returned. (Example) If channel 12 is currently in the CONTACT FAIL status, 12 is returned. TOS9213S/ TOS9213AS 7-35...
Page 160: System-Related Messages
0.2 to 10.0, HOLD Unit: (Example) To set the PASS hold time to HOLD, PHOL HOLD Response To PHOL?, the current PASS hold time is returned. (Example) If the current PASS hold time is 0.5 s, 0.5 is returned. 7-36 TOS9213S/ TOS9213AS...
Page 161 Data format: Integer Set value: 0 to 10 Resolution: (Example) To set the LCD contrast to 5, CON 5 Response To CON?, the current LCD contrast is returned. (Example) If the current LCD contrast is 6, 6 is returned. TOS9213S/ TOS9213AS 7-37...
Page 162 1 is returned. FAILMODE (FMOD) Sets the FAIL mode (FAIL MODE). Also inquires about the current FAIL mode setting. Message Setting: FAILMODE_<{ON|OFF}> FMOD_<{ON|OFF}> FAILMODE? Query: FMOD? Program data Data format: Character Set value: OFF (0), ON (1) 7-38 TOS9213S/ TOS9213AS...
Page 163 (Example) To set H.V ON of Status Signal Output to OFF, SHV OFF Response To SHV?, the current H.V ON setting for Status Signal Output is returned. (Example) If H.V ON for Status Signal Output is currently set to ON, 1 is returned. TOS9213S/ TOS9213AS 7-39...
Page 164 (Example) If the PASS status of Status Signal Output is currently set to ON, 1 is returned. SIGUFAIL (SUF) Sets U FAIL for Status Signal Output. Also inquires about the current U FAIL setting. Message Setting: SIGUFAIL_<{ON|OFF}> SUF_<{ON|OFF}> SIGUFAIL? Query: SUF? Program data Data format: Character 7-40 TOS9213S/ TOS9213AS...
Page 165 (Example) To set the READY status of Status Signal Output to OFF, SREA OFF Response To SREA?, the current READY setting for Status Signal Output is returned. (Example) If the READY status of Status Signal Output is currently set to ON, 1 is returned. TOS9213S/ TOS9213AS 7-41...
Page 166 (Example) If the POWER ON status of Status Signal Output is currently set to ON, 1 is returned. SIGCFAIL (SCF) Sets C FAIL for Status Signal Output. Also inquires about the current C FAIL setting. Message Setting: SIGCFAIL_<{ON|OFF}> SCF_<{ON|OFF}> SIGCFAIL? Query: SCF? 7-42 TOS9213S/ TOS9213AS...
Page 167 (Except 22H ("), 27H ('), 2CH (,), 3BH (;), and 40H (@)) Put Set value in 22Hs (".) (Example) To enter “KIKUSUI” in the 1st line, a blank in the 2nd line, and “TOS9213S” in the 3rd line, COM "KIKUSUI"," ","TOS9213S"...
Page 168: Memory-Related Messages
Recalls the contents of memory stored in an insulation resistance test Message Setting: IR:RECALL_<memory number> I:REC_<memory number> Program data Data format: Integer Set value: 0 to 99 Resolution: (Example) To recall memory 10 for insulation resistance testing, I:REC 10 7-44 TOS9213S/ TOS9213AS...
Page 169 (the existing memory name is not replaced). Message Setting: IR:STORE_<memory number> I:STOR_<memory number> Program data Data format: Integer Set value: 0 to 99 Resolution: (Example) To store the current settings for an insulation resistance test to memory I:STOR 10 TOS9213S/ TOS9213AS 7-45...
Page 170 <test time> Program data Data format: Real number Set value: 0.3 to 999 Resolution: 0.1 for 0.3 to 99.9, 1 for 100 to 999 Unit: <lower judgment{ON|OFF}> Program data Data format: Character Set value: OFF, ON (0, 1) 7-46 TOS9213S/ TOS9213AS...
Page 171 20%, voltage rise time of 0.2 s, WAIT TIME of 0.5 s, GND set to LOW, contact check set to ON, scanners 1 through 5 set to Low, scan- ners 6 through 10 set to High, and the other scanners set to Open, then, “DCW12,5.50E3,5.00E-3,5.00E-3,2.0,1,1,20,0.2, 0.5,0,1,992,64512” is returned. TOS9213S/ TOS9213AS 7-47...
Page 172 0.01 E6 (0.01 E6 to 9.99 E6), 0.1 E6 (10.0 E6 to 99.9 E6) 1 E6 (100 E6 to 999 E6), 0.01 E9 (1.00 E9 to 9.99 E9) Ω Unit: • Current value-based judgment Set value: 0.1 E-6 to 1.00 E-3 7-48 TOS9213S/ TOS9213AS...
Page 173 LOW is represented by 0 and HIGH by 1. Program data <scanner Open> Data format: Integer Set value: 0 to 65535 (#HFFFF) Resolution: OPEN is represented by 1 and NOT OPEN by 0. OPEN has priority over HIGH/LOW. TOS9213S/ TOS9213AS 7-49...
Page 174: Program-Related Messages
(Example) To name program 10 “TEST 10,” PNAM 10,"TEST 10" Response To PNAM?_<program number>, the name of the program with the specified number is returned. (Example) If the name of program 10 is TEST10, “TEST10” is returned. 7-50 TOS9213S/ TOS9213AS...
Page 175 Set value: 1: DCW; 2: IR; 3: EC <memory number> Program data Data format: Integer Set value: 0 to 99 Resolution: <interval time> Program data Data format: Real number, character Set value: 0.2 to 9.9, HOLD Resolution: Unit: TOS9213S/ TOS9213AS 7-51...
Page 176 OFF (0), ON (1) (Example) To set program 10 to RETURN, PRET 10,ON Response To PRET?_<program number>, the RETURN setting for the specified program is returned. (Example) If program 10 is set to the END mode, 0 is returned. 7-52 TOS9213S/ TOS9213AS...
Page 177 Data format: Integer Set value: 0 to 99 Resolution: Response To PRET?_<program number>, the total number of steps in a specified program is returned. (Example) If the total number of step in program 10 is 55, 55 is returned. TOS9213S/ TOS9213AS 7-53...
Page 178 • Up to 500 steps can be used in a set of programs. For example, if 100 steps are set for each of programs 0 to 4, no step is available for program 5. (Example) To insert memory 3 for DC withstanding voltage testing into step 15 of program 10, PIN 10,15,1,3 7-54 TOS9213S/ TOS9213AS...
Page 179 Inquires which step the program is currently executing Message AUTORUNNING? Query: ARUN? Response To ARUN?, the step currently being executed by the program is returned. (Example) If step 55 of the program is being executed, 55 is returned. TOS9213S/ TOS9213AS 7-55...
Page 180: Registers
Read by *STB? & & Logical & & & & Service-request & enable register This register is set by *SRE and read ESB DSB by *SRE?. (Initial value: 70H) Fig.7-6 Structure of status data 7-56 TOS9213S/ TOS9213AS...
Page 181 Indicates that an invalid message has been received during the test or in the EXE (Execution Error) protection status Not used with this tester Not used with this tester Not used with this tester Not used with this tester TOS9213S/ TOS9213AS 7-57...
Page 182 AUTO test is disconnected. INTERLOCK In the INTERLOCK status 10 %±50 V (Setting 10 %±50 V) When the test voltage has deviated from 10% ±50 V 100/200 (Select 100/200) When a source voltage outside the preset range has been applied 7-58 TOS9213S/ TOS9213AS...
Page 183 Not used with this tester Not used with this tester Not used with this tester Invalid message Indicates an invalid message Out-of-range error Indicates an out-of-range error Data Error Indicates a data error Syntax Error Indicates a header error TOS9213S/ TOS9213AS 7-59...
Page 184: Message List
Unit Note 1 Note 2 Initializes devices. ➀ ➀ *RST (Resets to factory settings, except for the INTER- FACE screen settings) Returns “KIKUSUI ELECTRONICS CORP., ➀ ➀ *IDN? TOS9200, 0, x.xx”. ➀ ➀ ERR? Returns an error value and clears it.
Page 185: Messages For Dc Withstanding Voltage Testing
Returns a WORD-type value for Hi/Low and Open/ ➀ ➀ (D:SCANW?) Not Open. DCW:CONTACT ➁ ➁ Sets ON/OFF of the scanner contact check function. CHECK (D:CCH) DCW:CONTACT Returns the ON/OFF status of the scanner contact ➀ ➀ CHECK? (D:CCH?) check function. TOS9213S/ TOS9213AS 7-61...
Page 186: Messages For Insulation Resistance Testing
0: Low and 1: Hi, using 16 bits. The 2nd data repre- IR:SCANW ➁ ➁ sents Open and Not Open, with 1 for Open. (I:SCANW) 65535 The Open setting for the 2nd data has priority over #HFFFF the 1st data. 7-62 TOS9213S/ TOS9213AS...
Page 187: Messages Common To All Tests
Sets ON/OFF for the scanner contact check function. CHECK (I:CCH) IR:CONTACT Returns the ON/OFF status of the scanner contact ➀ ➀ CHECK?(I:CCH?) check function. *1. “1020” for TOS9213S, whereas “1530” for TOS9213AS. 7.6.4 Messages common to all tests Data Header Function and response data Min. Max.
Page 188: System-Related Messages
Sets the value of Status Signal Output: CONTACT ➀ ➀ SIGCFAIL (SCF) OFF/ON FAIL. ➀ ➀ SIGCFAIL? (SCF?) ON/OFF is returned as 1 or 0. SIGPOWERON ➀ ➀ OFF/ON Sets the value of Status Signal Output: POWER ON. (SPOW) 7-64 TOS9213S/ TOS9213AS...
Page 189 Comment (memo) 20 characters in the 3rd line *1 *1: 20H to 7EH are ASCII code. Put Set value in 22Hs (".) Except (“), (‘), (,), (;), and (@) COMMENT? --,--, Returns a comment (memo). ➀ ➀ (COM?) 1st line, 2nd line, 3rd line TOS9213S/ TOS9213AS 7-65...
Page 190: Memory-Related Messages
WAIT TIME, response filter setting ➀ ➀ (D:MEM?) (0/1/2), GND, contact check, scanner Hi/Low, scanner Open). ON/OFF is returned as 1 or 0. Scanner Hi/Low and scanner Open are returned in decimal form using 16 bits. 7-66 TOS9213S/ TOS9213AS...
Page 191 ON/OFF, timer ON/OFF, voltage rise time, WAIT IR:MEMORY? ➀ ➀ TIME, GND, contact check, scanner Hi/Low, scanner (I:MEM?) Open). ON/OFF is returned as 1 or 0. Scanner Hi/Low and scanner Open are returned in decimal form using 16 bits. TOS9213S/ TOS9213AS 7-67...
Page 192: Program-Related Messages
PRGDEL ➁ ➁ (PDEL) Program step number AUTORUNNING? Returns the step currently being executed by a pro- ➀ ➀ (ARUN?) gram. Note 3: When PRGEDIT (PED) or PRGINS (PIN) is executed, the program EDIT screen automatically appears. 7-68 TOS9213S/ TOS9213AS...
Page 193: Chapter 8 Controlling The Tos6200
Chapter 8 Controlling the TOS6200 This chapter describes the procedure for using the tester to control Kikusui’s earth continuity tester TOS6200 via the RS-232C interface. This control function is used to recall and execute the test conditions stored in the TOS6200’s memory by executing the tester’s program.
Page 194: Pre-Control Preparation
It is necessary to preset test conditions for the TOS6200 in panel memory. In the TOS6200, memories 1 through 18 contain factory settings that conform to the relevant safety standards. To add new test conditions, use memories 19 through 99. TOS9213S/ TOS9213AS...
Page 195: Settings On The Tos9213S/ Tos9213As
8.1.3 Settings on the TOS9213S/ TOS9213AS Interface settings On the tester, press the SHIFT + SYSTEM /I/F keys. The LED then lights up on the SYSTEM /I/F key, and the Interface Settings screen (INTERFACE) appears. On this screen, make the settings specified below.
Page 196 Position the cursor at the step to be inserted. Press the F1 key (INS) to insert a step (DCW00-0.2s) at the cursor position. Using the key, move the cursor to “DCW” to the right of the step num- ber. Using the rotary knob, select EC. TOS9213S/ TOS9213AS...
Page 197 The Program screen displays the total number of steps thus set. The tester enters the READY status. Program No. Step No. Program name Repeat settings READY AUTO AUTO 00 : --UNTITLED-- 01 EC 00-1.0s 02 IR 02-1.0s 03 EC 03-1.0s TOTAL:10 Total number of steps Test step TOS9213S/ TOS9213AS...
Page 198: Starting A Test
On the TOS6200, display the Test Condition Settings screen (MAIN). The tester forcibly shifts the TOS6200 to the Test Condition Settings screen (MAIN). ■ TOS9213S/ TOS9213AS On the tester, display the Program screen (AUTO). (To display the Program screen (AUTO), press the AUTO key.) Checking the TOS6200 status Confirm that the TOS6200 is in the READY status.
Page 199: Test Judgement
• The RS-232C cable is disconnected or broken. • At the start of a test, the TOS6200 is not in the READY status. To cancel a communication error, press the STOP switch. Eliminate the cause of the communication error, and restart the test. TOS9213S/ TOS9213AS...
Page 200: Canceling The Tos6200 Control Mode
On the tester and the TOS6200, turn off the POWER switch. On the rear panel of the tester and the TOS6200, disconnect the RS- 232C cable from the RS-232C connector. To use either the tester or the TOS6200 alone, turn on the POWER switch. TOS9213S/ TOS9213AS...
Page 201: Chapter 9 Maintenance
Chapter 9 Maintenance This chapter describes the maintenance, inspection, and calibration of the tester. Regular maintenance and inspection are necessary to maintain the initial perfor- mance of the product. TOS9213S/ TOS9213AS...
Page 202: Cleaning
• Tearing and breakage of the cable coating may lead to electric shock and fire. In such a case, immediately discontinue use of the tester. To purchase accessories, contact Kikusui distributor/agent. ■ AC Power cord Check for tears in the cable coating, looseness and fracture of the plug, and break- age of the cable.
Page 203: Maintenance
Maintenance WARNING • To replace components, the tester cover must be opened, but only by our service representative. Contact your Kikusui agent/distributor if it is neces- sary to perform replacement work. ■ High-voltage relay The high-voltage relays inside the tester are consumable. Although service life depends on the usage environment, we recommend that the high-voltage relays be replaced every one million tests.
Page 204: Troubleshooting
Not all problems involve mechanical failures. Before requesting repair service, recheck your problem. Find your problem in the list below, and correct it as instructed. If it still persists or if you cannot find it in the list, contact Kikusui distributor/agent Problem Checkpoint...
Page 205: Chapter 10 Specifications
Chapter 10 Specifications This chapter describes the electrical and mechanical specifications for the tester. TOS9213S/ TOS9213AS 10-1...
Page 206: 10.1 Withstanding Voltage Test Mode
If you set the discharge time to 0.0 s or if the voltage between the output terminals exceeds approximately 30 V even after the specified discharge time has passed, the TOS9213S/ TOS9213AS will continue discharging until the voltage between the output terminals falls below approximately 30 V.
Page 207 2.01 mA to 5.50 mA: ±(3 % of reading+10 μA) The absolute current values are integrated and compared with the reference Current detection method value. The current detection response for UPPER FAIL judgement can be set to FAST/ Response switching function MID/SLOW (*5) TOS9213S/ TOS9213AS 10-3...
Page 208 Never ground the DUT. In ordinary operation, set the GND to LOW. *5 In the MID and SLOW modes, depending on the discharge method, the voltage monitoring function may operate and the TOS9213S/ TOS9213AS may enter the PROTECTION status before UPPER FAIL detection takes place. 10-4...
Page 209: 10.2 Insulation Resistance Testing Mode
*2.About the discharge time setting: If you set the discharge time to 0.0 s or if the voltage between the output terminals exceeds approximately 30 V even after the specified discharge time has passed, the TOS9213S/ TOS9213AS will continue discharging until the voltage between the output terminals falls below approximately 30 V.
Page 210 (UPPER) 0.1 µA to 1.00 mA based judgment Resistance Setting range 0.01 MΩ to 9.99 GΩ [Below the maximum rated current] value-based for the lower judgment reference Current value- (LOWER) 0.1 µA to 1.00 mA based judgment 10-6 TOS9213S/ TOS9213AS...
Page 211 0.5 s to 999 s With the TIMER OFF function (TEST TIME) Accuracy ± (100 ppm + 20 ms) Setting range for the judge- 0.3 s to 10 s ment wait time (WAIT TIME) [(RISE TIME + TEST TIME) > WAIT TIME] TOS9213S/ TOS9213AS 10-7...
Page 212: 10.3 Interface And Other Functions
Input terminal for the STOP signal ENABLE Input terminal for the ENABLE signal for the START signal Output terminal for +24 V internal power, with a maximum output current of +24 V 100 mA Circuit common (chassis potential) 10-8 TOS9213S/ TOS9213AS...
Page 213 GPIB ten-only function Expansion listener No function Service request All functions provided Remote local All functions provided Parallel port No function Device clear All functions provided Device trigger No function Controller No function Electrical interface Open collector TOS9213S/ TOS9213AS 10-9...
Page 214 Starts a test only when the START switch is pressed within approximately DOUBLE ACTION 0.5 s after the STOP switch is pressed Shifts to the status in which no keys other than the START and STOP KEYLOCK switches are accepted 10-10 TOS9213S/ TOS9213AS...
Page 215: 10.4 General Specifications
*2.Pollution is addition of foreign matter (solid, liquid or gaseous) that may produce a reduction of dielectric strength or sur- face resistivity. Pollution Degree 2 assumes that only non-conductive pollution will occur except for an occasional tempo- rary conductivity caused by condensation. TOS9213S/ TOS9213AS 10-11...
Page 216: 10.5 Dimensions
10.5 Dimensions MAX455 (17.91) MAX10 (0.39) 430 (16.93) Unit: mm (inch) Fig.10-1 Dimensions 10-12 TOS9213S/ TOS9213AS...
Page 217: Appendix
GUARD AC line [10] POWER SUPPLY Fig.A-1 TOS9213S/ TOS9213AS block diagram [1] Reference-voltage generation circuit Generates a reference voltage corresponding to the test voltage in DC withstanding voltage testing and insulation resistance testing. During the preset voltage rise time (RISE TIME), the reference voltage increases from zero to the preset test voltage, exerting little transient voltage stress on the DUT.
Page 218 A/D converter. The insulation resis- tance value is determined by dividing the voltage measured on the voltmeter for insulation resistance testing by the current obtained in this current detection circuit. The insulation resistance value is then displayed on the LCD. TOS9213S/ TOS9213AS...
Page 219: Ascii Code 20H To 7Eh
Turn the rotary knob counterclockwise to enter ASCII code [ ] (20H). Turn the rotary knob clockwise to enter ASCII code [~] (7E). NOTE • The tester does not accept [“] (22H), [‘] 27H, [,] (2CH), or [@] (40H). TOS9213S/ TOS9213AS...
Page 220 TOS9213S/ TOS9213AS...
Page 221: Index
IR:TIMER (I:TIM) ........... 7-28 C FAIL ..........5-47, 7-35, 7-42 IR:UPPER (I:UPP) ..........7-26 calibration ............... 9-3 IR:WAITTIME (I:WTIM) ......... 7-29 channel ............5-18, 5-34 LOCAL (LOC) ............7-14 Class I equipment ........... 2-7 MEASMODE (MMOD) .......... 7-36 TOS9213S/ TOS9213AS...
Page 222 ............7-7, 7-60 GPIB cable .............. 7-2 MID ................5-13 GPIB functions ............7-2 MOMENTARY ..........5-44, 7-38 ground (earth) ............2-7 monitor current ............7-33 GUARD ............5-16, 5-32 monitor resistance ..........7-34 monitor voltage ............7-33 monitoring of AC line ..........5-59 TOS9213S/ TOS9213AS...
Page 223 ....... 5-26 U FAIL ............5-47, 7-40 RESPONSE ............5-12 unpacking ............... 2-2 response-message terminator .......7-9, 7-15 UP<=LOW ............5-57 RET ............... 5-55 UPPER ............5-8, 5-24 RETURN ............... 7-52 upper judgement function ON/OFF ....... 5-24 TOS9213S/ TOS9213AS...
Page 224 ......5-8, 5-24, 7-17, 7-26 voltage rise time ......5-10, 5-28, 7-19, 7-28 WAIT TIME ........5-12, 5-29, 7-20, 7-29 TOS9213S/ TOS9213AS...
Page 226 In either case, please contact your Kikusui agent or distributor. At that time, inform your agent or distributor of the “Part No.” written on the front cover of this manual.

This manual is also suitable for:

Tos9213as

Kikusui TOS9213S Operation Manual

Chapter 1 Preface

Chapter 2 Setup

Chapter 3 Precautions on Handling

Chapter 4 Part Names and Functions

Chapter 5 Basic Operations

Chapter 6 Using Terminals and Connectors

Chapter 7 GPIB/RS-232C Interface

Chapter 8 Controlling the TOS6200

Chapter 9 Maintenance

Chapter 10 Specifications

Appendix

Index

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kikusui TOS9213S

This manual is also suitable for:

Table of Contents
