8 Verification and Calibration
Current Calibration
High Range Programming and Measurement
The output voltage may go negative at some point during this procedure on units that
have polarity reversal relays (Option 760).
Step 1. Connect a precision shunt resistor to the output. The shunt resistor should be able to measure
at least 120% of the output's full-scale current (see
across the shunt resistor.
Step 2. Select the full-scale current programming range. The value to program a range must be the
maximum current of the range. The following example selects the 3 A full-scale range of output 1.
Full-scale ranges vary according to model.
Front Panel Menu Reference
From the Calibration menu, select Current, High Range Prog and Meas. Then
select Start.
Step 3. Select the first current calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Calculate the shunt current (I=V/R)
and enter the data.
Press Select when done.
Step 4. Select the second current calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P2 measured data"
Calculate the shunt current (I=V/R) and enter the data. Press Select when done.
Press Next to finish calibration.
Low Range Current Measurement
Step 1. Connect only the current measurement terminals of the Keysight 3458A to the output
terminals (see Cal Setup D
Step 2. Select the low-current measurement range. The value to program a range must be the
maximum current of the range. This example selects the 100 mA range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Current, Low Range Measurement. Then
select Start.
Step 3. Select the first current calibration point and enter the data.
410
without the resistor).
Cal Setup B). Connect the Keysight 3458A DMM
SCPI Command
CAL:CURR 3, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
CAL:CURR:MEAS 0.15, (@1)
