Low Range Voltage Programming - Models N6761A through N6766A
Step 1. Select the low-voltage programming range. The value entered must be the maximum voltage
of the range to be calibrated. This example selects the 5 V range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Voltage, Low Range Programming. Then select
Start.
Step 2. Select the first voltage calibration point and enter the data. This value may be positive or
negative.
Front Panel Menu Reference
Display shows: "Enter P1 measured data"Enter the data from the external DMM.
Press Select when done.
Step 3. Select the second voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P2 measured data"Enter the data from the external
DMM.Press Select when done.
Press Next to finish calibration.
Low Range Voltage Measurement - Models N6761A through N6766A
Step 1. Select the low-voltage measurement range. The value entered must be the maximum voltage
of the range to be calibrated. This example selects the 5 V range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Voltage, Low Range Measurement. Then select
Start.
Step 2. Select the first voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data"Enter the data from the external DMM.
Press Select when done.
Step 3. Select the second voltage calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P2 measured data"Enter the data from the external DMM.
Press Select when done.
Press Next to finish calibration.
Keysight N6705C Operating and Service Guide
8 Verification and Calibration
SCPI Command
CAL:VOLT 5, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
CAL:VOLT:MEAS 5, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
