7 SCPI Programming Reference
Parameter
DWELl | TRIGgered, *RST DWELl
Step 0 - 99, *RST 0
Specify trigger pacing for sequence step 1: ARB:SEQ:STEP:PAC TRIG, 1, (@1)
If the <step#> specified is an existing sequence step, that step will be changed to the specified
l
waveshape with all parameters reset to default values.
New sequence steps must be specified sequentially. To create a new sequence step, <step#>
l
should be specified to be the current length of the sequence (see
[SOURce:]ARB:SEQuence:LENgth?). When a step is added, all parameters of the step waveform
are reset to their default values.
[SOURce:]ARB:SEQuence:TERMinate:LAST <Bool>, (@<chanlist>)
[SOURce:]ARB:SEQuence:TERMinate:LAST? (@<chanlist>)
Determines the output value when the Arb sequence terminates. The state is either ON (1) or OFF (0).
When The output voltage or current remains at the last Arb sequence value. The last voltage or current Arb value becomes the IMMediate
ON value when the sequence completes.
When The output returns to the settings that were in effect before the sequence started. This also applies when the sequence is aborted,
OFF
0|OFF|1|ON, *RST Off
Sets the sequence to terminate with the voltage or current set at the last sequence value:
ARB:SEQ:TERM:LAST ON,(@1)
The query returns 0 if the output returns to the settings that were in effect before the sequence
l
started, and 1 if the output voltage or current remains at the last sequence value.
266
Parameter
Typical Return
DWEL or TRIG
(none)
Typical Return
0 or 1
