Keysight N6705C Operating And Service Manual page 405

100 mA Measurement Range - All Models
Step 1. Connect only the current measurement terminals of the Keysight 3458A to the output
terminals (see Cal Setup D
Step 2. Select the 100 mA measurement range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Current, 100 mA Measurement Range. Then
select Start.
Step 3. Select the first current calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Measure the current with the Keysight
3458A and enter the data.
Press Select when done.
Step 4. Select the second current calibration point for the negative range and enter the data. The
value should be negative.
Front Panel Menu Reference
Display shows: "Enter P2 measured data"
Measure the current with the Keysight 3458A and enter the data. Press Select
when done.
1 mA Measurement Range - All Models
Step 1. Connect the Keysight 3458A in series with a 10 kΩ resistor to the output (see
Required and Cal Setup
Step 2. Select the 1 mA measurement range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Current, 1 mA Measurement Range. Then
select Start.
Step 3. Select the first current calibration point and enter the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Measure the current with the Keysight
3458A and enter the data.
Press Select when done.
Step 4 applies only to models N6781A, N6782A, and N6784A
Step 4. Select the second current calibration point for the negative range and enter the data. The
value should be negative.
Keysight N6705C Operating and Service Guide
without the resistor).
D).
8 Verification and Calibration
SCPI Command
CAL:CURR:MEAS 0.1, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
CAL:CURR:MEAS 0.001, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
Equipment
405
