7 SCPI Programming Reference
Parameter
A decimal value that corresponds to the binary-weighted sum of the bits
in the register.
Enable bit 3 and 4 in the enable register: STAT:OPER:ENAB 24, (@1)
*CLS does not clear the enable register, but does clear the
l
STATus:OPERation:NTRansition <value>, (<@chanlist>)
STATus:OPERation:NTRansition? (<@chanlist>)
STATus:OPERation:PTRansition <value>, (<@chanlist>)
STATus:OPERation:PTRansition? (<@chanlist>)
Sets and queries the value of the
These registers serve as a polarity filter between the Operation Condition and Operation Event
registers.
When a bit in the NTR register is set to 1, then a 1-to-0 transition of the corresponding bit in the
Operation Condition register causes that bit in the Operation Event register to be set.
When a bit in the PTR register is set to 1, then a 0-to-1 transition of the corresponding bit in the
Operation Condition register causes that bit in the Operation Event register to be set.
STATus:PRESet sets all bits in the PTR registers and clears all bits in the NTR registers.
Parameter
A decimal value that corresponds to the binary-weighted sum of the bits
in the register.
Enable bit 3 and 4 in the NTR register: STAT:OPER:NTR 24, (@1)
Enable bit 3 and 4 in the PTR register: STAT:OPER:PTR 24, (@1)
If the same bits in both NTR and PTR registers are set to 1, then any transition of that bit at the
l
Operation Condition register sets the corresponding bit in the Operation Event register.
If the same bits in both NTR and PTR registers are set to 0, then no transition of that bit at the Oper-
l
ation Condition register can set the corresponding bit in the Operation Event register .
The value returned is the binary-weighted sum of all bits set in the register.
l
STATus:PRESet
Presets all Enable, PTR, and NTR registers.
Operation register
STAT:OPER:ENAB
STAT:OPER:NTR
STAT:OPER:PTR
328
NTR (Negative-Transition) and
Questionable register
STAT:QUES:ENAB
STAT:QUES:NTR
STAT:QUES:PTR
Typical Return
<bit value>
event register.
PTR (Positive-Transition) registers.
Typical Return
<bit value>
Preset setting
all defined bits are disabled
all defined bits are disabled
all defined bits are enabled
