  • Page 1 C O N F I G U R A T I O N G U I D E PNA Family Microwave Network Analyzers (N522x/3x/4xB)

  • Page 2: Table Of Contents

    Hardware options....................................06 Application software ....................................07 Accessories, calibration options ................................09 PNA-X Series Test Set and Power Configuration Options ..........................10 PNA Series Test Set and Power Configuration Options ............................15 PNA-L Series Test Set and Power Configuration Options ..........................18 PNA Family Applications and Options ................................19 Measurement application software ................................19...
  • Page 3 This configuration guide describes standard configurations, options, accessories, upgrade kits and compatible peripherals for the PNA Family microwave network analyzers. This guide should be used with the Keysight Technologies, Inc. PNA Family data sheets for a complete description of these analyzers.
  • Page 4 Keysight Offers the Following Options for All PNA Family Network Analyzers Certification options Documentation Commercial calibration certification with test data The PNA Series instruments are equipped with an Online Help system available within the instrument in English only. All PNA...

  • Page 5: Pna Family Network Analyzer Configurations

    1. To independently control the frequency of the second internal source, one of the following software applications is required: S93080/029/082/083/084/086/087/089/090x/093/094A, or S94510/511A. 2. Adds one source attenuator to be shared with all test ports. Page 5 Find us at www.keysight.com...

  • Page 6: Hardware Options

    For N5241/42/49B, requires one of options 21x, 22x, 41x, or 42x. For N5244/45/47B, requires one of options 22x or 42x. On N5247B, noise receiver works up to 50 GHz only. Page 6 Find us at www.keysight.com...

  • Page 7: Application Software

    Noise calibration requires a power meter when using a standard receiver. When using the low-noise receiver (Option 029), either a power meter or a 346-series noise source is required (Keysight 346C or 346C-K01 recommended). A power meter is required for measuring mixers and converters.
  • Page 8 When N524xB is configured as a multiport analyzer using S93551B/A and a multiport test set, the combiner feature of Option 22x or 42x is temporarily disabled. When configured as a standalone analyzer, the combiner feature is enabled. A fully configured NVNA system requires two comb generators with power supplies, Keysight calibration kits (mechanical or ECal), and a power meter and sensor or USB power sensor.

  • Page 9: Accessories, Calibration Options

    N522xB-A6J N523xB-A6J 1. A fully configured NVNA system requires two comb generators with power supplies, Keysight calibration kits (mechanical or ECal), and a power meter and sensor or USB power sensor. 2. Additional hardware required. Please refer to the analyzer’s service guide for required service-test equipment.

  • Page 10: Pna-X Series Test Set And Power Configuration Options

    PNA-X Series Test Set and Power Configuration Options 2-ports, single source, with configurable test set The PNA-X is an integrated vector network analyzer featuring a built-in S-parameter test set, one or two synthesized sources and low frequency extension (Option 205)
  • Page 11 PNA-X Series Test Set and Power Configuration Options (Continued) 2-ports, single source, with extended power 2-ports, dual sources, with extended power range (Option 217) range, combiner, and mechanical switches (Option 222) This configuration comes with front-panel access loops, and source and receiver attenuators at each port. The...
  • Page 12 PNA-X Series Test Set and Power Configuration Options (Continued) 2-ports, dual sources, with extended power To independently control the frequency of the second internal source, one of the following software applications is required: range, bias tees, and mechanical switches S93080/029/082/083/084/086/087/089/090x/093/094B/A.
  • Page 13 PNA-X Series Test Set and Power Configuration Options (Continued) 4-ports, dual sources, with extended power range 4-ports, dual sources, with extended power and bias-tees (Option 419) range, combiner, and mechanical switches (Option 422) This configuration comes with two sources, front-panel access...
  • Page 14 PNA-X Series Test Set and Power Configuration Options (Continued) 4-ports, dual sources, with extended power 4-ports, dual sources, with extended power range, bias tees, combiner, and mechanical range, bias tees, combiner, mechanical switches, switches (Option 423) and low-frequency extension (Option 425)

  • Page 15: Pna Series Test Set And Power Configuration Options

    In addition, the combiner type and attenuator values vary by model number. Refer to the product data sheet To receivers for the correct block diagram for a specific model. Test port 1 Test port 2 Page 15 Find us at www.keysight.com...
  • Page 16 In addition, the combiner type and attenuator values vary by model number. Refer to the product data sheet for the correct block diagram for a specific model. Page 16 Find us at www.keysight.com...
  • Page 17 In addition, the combiner type and attenuator values vary by model number. Refer to the product data sheet for the correct block diagram for a specific model. Page 17 Find us at www.keysight.com...
  • Page 18 In addition, the combiner type and attenuator values vary by model number. Refer to the product data sheet for the correct block diagram for a specific model. Page 18 Find us at www.keysight.com...

  • Page 19: Pna-L Series Test Set And Power Configuration Options

    The source attenuators are settable in 10 dB steps up to 60 dB. Source To receivers 60 dB 60 dB Test port 1 Test port 2 Test port 3 Test port 4 Test port 1 Test port 2 Page 19 Find us at www.keysight.com...

  • Page 20: Pna Family Applications And Options

    LO signals. Supported external sources adding PLTS software. Jitters and/or emphasis/equalization include the Keysight ESG, PSG, EXG, and MXG Series, as well capabilities enables simulation of real-world signals and as other SCPI-controlled signal generators. S93082B/A is a environment.
  • Page 21 LO signals. measurements. When configured with PNA-X Option 22x or 42x, Supported external sources include the Keysight ESG, PSG, the two internal sources and internal combiner can be used for EXG, and MXG Series, as well as other SCPI-controlled signal two-tone IMD measurements.
  • Page 22 When using S93093B/A for millimeter-wave spectrum analysis, an N5261/62A or an N5292A millimeter-wave controller is required. When S93093B/A is installed on a standalone network analyzer, it will provide spectrum analysis up to the frequency limit of the instrument. Page 22 Find us at www.keysight.com...
  • Page 23 PNA-X PNA-L files have 144 S-parameter elements). Active hot parameters allows the PNA-X Series a more accurate method for testing Hot S-parameter, gain and output power than traditional methods by utilizing the X-parameter technology. It removes active device and system interaction to precisely calculate the active parameters and output power into a nominal 50 Ω...

  • Page 24: Noise Figure Options And Applications

    This software application enables high-accuracy noise figure and calibration accessories must be ordered separately. noise-power measurements of amplifiers, frequency converters, and mixers, utilizing Keysight’s unique vector-source-correction Add mechanical noise tuner control for noise technique that uses a source-impedance tuner to remove the figure/parameter measurements (S93027B/A ) effects of imperfect system-source match.

  • Page 25: Pna-X Block Diagrams With Noise Figure Option

    Test port 3 Test port 4 Test port 2 S93029B/A software is required to control the impedance tuner and tuner switch at port one, and the noise receiver and noise switch at port two. Page 25 Find us at www.keysight.com...

  • Page 26: Noise Figure Measurement Summary

    2. External preamplifier and filter(s) required if DUT excess noise (gain plus noise figure) is < 30 dB up to 20 GHz, < 40 dB up to 50 GHz, or < 45 dB up to 67 GHz. 3. Only N4690 Series ECal modules are supported for use as an impedance tuner. Page 26 Find us at www.keysight.com...
  • Page 27 1. External preamplifier and filter(s) required if DUT excess noise (gain plus noise figure) is < 30 dB up to 20 GHz, < 40 dB up to 50 GHz, or < 45 dB up to 67 GHz. Page 27 Find us at www.keysight.com...

  • Page 28: Pulse, Antenna, Mm-Wave Applications And Options

    S93026B/A also controls Please refer to 5989-8575EN Nonlinear Vector Network external pulse generators and modulators, and can synchronize Analyzer Brochure for more information. Page 28 Find us at www.keysight.com...

  • Page 29: Accessories

    – 85523B CalPod controller (provides control for up to 4 CalPods) – 85556A CalPod drive-cable splitter (allows control for up to 12 CalPods) – 85554A CalPod drive cable extension (10-meter cascadable extension cable) Pulse I/O adapter (N1966A) simplifies connections Page 29 Find us at www.keysight.com...
  • Page 30 Node locked License can be used on one specified instrument/computer. Transportable License can be used on one instrument/computer at a time but may be transferred to another using Keysight Software Manager (internet connection required). USB portable License can be used on one instrument/computer at a time but can be transferred to another using a certified USB dongle (available for additional purchase, Keysight part number E8900-D10).
  • Page 31 X 24 months L 12 months Y 36 months X 24 months Z 60 months Y 36 months 1. USB portable license requires a certified USB dongle (available for additional purchase, Keysight part number E8900-D10) Page 31 Find us at www.keysight.com...

  • Page 32: Pna Family Network Analyzer Upgrade Kits

    Add internal 2nd source, combiner and mechanical N524xB-217/219 N524xBU-224 switches, 2-ports 1. Frequency upgrade options from 8.5/13.5/20/26.5 GHz to 43.5/50 GHz and 43.5/50 GHz to 67 GHz are not available. Trade-in is recommended. 2. Not available on N5227/47B. Page 32 Find us at www.keysight.com...
  • Page 33 N523xAU-690 with 12.1” multi-touch display, a new solid-state hard drive, and a new instrument cover and handles with Keysight’s dark-gray color scheme 1. Not available on N5227/47B. 2. May also require update of CPU, SPAM, and synthesizer assemblies, supplied in separate upgrade kits.

  • Page 34: Upgrade Paths

    13.5 GHz 50 GHz N5231BU-620 20 GHz N5239BU-620 1. This upgrade path only available for N5241/42/49B. 2. This upgrade path only available for N5227B and N5247B. 3. This upgrade path only available for N5241/42B. Page 34 Find us at www.keysight.com...

  • Page 35: Applications

    Applications Material measurements Multiport measurements The Keysight N1500A materials measurement suite streamlines Multiport test sets are designed to work with the PNA family the process of measuring complex permittivity and permeability of network analyzers to provide a single set of connections to with a network analyzer.

  • Page 36: Test Set Options

    For use with N5221/22/41/42/49B-4xx 4-port PNA/PNA-X Option 245 For use with N5224/25/44/45B-2xx 2-port PNA/PNA-X Option 445 For use with N5224/25/44/45B-4xx 4-port PNA/PNA-X Option 247 For use with N5227/47B-2xx 2-port PNA/PNA-X Option 447 For use with N5227/47B-4xx 4-port PNA/PNA-X Page 36 Find us at www.keysight.com...

  • Page 37: Measurement Accessories

    Cables and adapter sets – Short standards (male and female) – Fixed-termination standards (male and female) Keysight offers cables in the following types: – Single cables in semi-rigid and flexible Standard, includes the devices in the economy kit and adds: –...

  • Page 38: For Devices With 1.0 Mm Connectors

    1.0 mm (m) to 2.4 mm (f) adapter – 11922D 1.0 mm (f) to 2.4 mm (m) adapter – 11923A 1.0 mm (f) connector launch assembly 1. For on-wafer applications, two 11500J/K/L cables are required; one cable for each test port. Page 38 Find us at www.keysight.com...

  • Page 39: For Devices With 2.4 Mm Connectors

    N469xD Series ECal. – 85058-60006 2.4 mm (f) to 2.4 mm (f) adapter 2. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector. Page 39 Find us at www.keysight.com...

  • Page 40: For Devices With K Connectors (2.92 Mm)

    2.4 mm (f) to PSC-2.4 mm (f), Keysight 85056KE01 calibration kit is an ordering convenience 81 cm, 32 inches to allow the pass through ordering from Keysight for the Maury – 85133D set, semi-rigid: One 2.4 mm (f) to 2.4 mm (m), 8770C47 calibration kit.
  • Page 41 Mechanical calibration kits, continued Cables Electronic calibration kits Note: Keysight offers the following 2.4 mm test port cables. N4692A Microwave ECal: 10 MHz to 40 GHz, 2-ports. Includes: Adapters will be necessary when using these cables for 2.92 mm – Option M0F module with: N4692-60001 2.92 mm (f) measurements.

  • Page 42: For Devices With 3.5 Mm Or Sma Connectors

    – 85052-60009 3.5 mm (f) open – 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter – 85052-60013 3.5 mm (f) to 3.5 mm (m) adapter – 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter Page 42 Find us at www.keysight.com...
  • Page 43 1. The PNA Series must have firmware revision A.12.85.00 or above for the operation with the N469xD Series ECal. 2. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector. Page 43 Find us at www.keysight.com...

  • Page 44: For Devices With Type-N Connectors

    Option 150: Replaces standard storage container with a wooden 2. The PNA Series must have firmware revision A.12.85.00 or above for the operation with the N469xD Series ECal. Page 44 Find us at www.keysight.com...

  • Page 45: For Devices With 7 Mm Connectors

    1. The PNA Series must have firmware revision A.12.85.00 or above for the operation with the N469xD Series ECal. 2. Special rugged female connector specifically for connecting to the network analyzer test port, but does not mate with a standard male connector. Page 45 Find us at www.keysight.com...

  • Page 46: Verification Kits

    – 11644-60013 W-band standard section For information about spare drives for older PNA models, please Verification kits refer to the configuration guide 5990-7745EN. All Keysight verification kits include: Probe – Precision Z airline or match thru – Mismatched airline or mismatch thru –...

  • Page 47: Comb Generators
