- Page 1 Keysight N6854A Geolocation System Configuration Guide...
- Page 2 120 or 240 VAC. This option is recommended for rapid setup and configuration prior to deployment. Option N6841A-GFP enables the RF Sensor to be used by the Keysight N6854A Geolocation Server Software. It is not required if the Sensor will only be used for spec- trum monitoring or signal analysis.
- Page 3 – New firmware that supports enhanced geo-location algorithms and faster signal processing. NOTE: If the RF Sensor has a sticker that reads “Upgraded to 5040”, it has already been upgraded. – For more information on the hardware upgrade, refer to Keysight Service Note N6841A-01.
- Page 4 Arrival (TDOA), Received Signal Strength (RSS) and Hybrid (adaptive TDOA RSS) algorithms on one PC. There is no cost associated with part number N6854A. However, it requires N6841A RF Sensors with option GFP enabled. As the RF Sensor network grows, additional Geo licenses can be obtained without added cost.
- Page 5 05 | Keysight | N6854A Geolocation System - Configuration Guide STEP 2. Configure the Software Applications (continued) N6820ES Signal Surveyor 4D Software Signal Surveyor 4D is spectrum monitoring software capable of automating signal search and survey functions. It tasks internal or external processes to capture and analyze spectrum events or conduct comprehensive surveys of the RF environment.
- Page 6 #5989-2839EN. 89601B Vector Signal Analysis (VSA) Software The VSA software is a widely used program capable of controlling many Keysight products including the N6841A. For more information, please refer to www.keysight.com/find/VSA VSA for the RF Sensor is typically configured as indicated below: –...
- Page 7 STEP 3. Consider the Geolocation Bundle for ease of ordering N6860A Keysight Geolocation bundle This is the easiest and best way to purchase a Keysight Geolocation system. With one part number, you get all the elements needed for a successful installation with exception of the User data network.
-
Page 8: Recommended Calibration Interval
An extended 5-year warranty is available for the RF Sensor and can be ordered at the time of hardware purchase by adding this part number: R-51B-001-5C Warranty Assurance Plan – Return to Keysight. This option is highly recommended especially if the Sensor is intended for outdoor deployment. - Page 9 09 | Keysight | N6854A Geolocation System - Configuration Guide Quote and Order Configuration Guide Sensors Quantity Remarks Part number Description N6841A N6841A RF Sensor N6841A-SP1 AC Power Supply (indoor only) N6841A-GPS GPS antenna N6841A-GFP Enables Sensor for Geolocation measurements N6841A-MFP Enables multiple DDC’s in the RF Sensor...
- Page 10 10 | Keysight | N6854A Geolocation System - Configuration Guide For more information on Keysight From Hewlett-Packard through Agilent to Keysight Technologies’ products, applications or services, please contact your local Keysight For more than 75 years, we‘ve been helping you unlock measurement insights.
