Digitizing Measurements
The digitizing measurements discussed in this section allow you to perform most but not all of the
scope measurement function available on the front panel. One example of functionality not available
over the remote interface is the ability to program markers and make calculated measurements
between markers.
With the digitizing measurement functions you can:
Specify a measurement function and range.
l
Adjust the measurement sample rate.
l
Adjust the measurement to capture pre-trigger data.
l
Select a measurement window that can attenuate AC noise.
l
Select the measurement trigger source.
l
Initiate the trigger system and generate a trigger.
l
Retrieve the digitized measurements.
l
When a measurement is in progress over the remote interface, the front panel display
may indicate "-- -- -- -- --". Front panel measurements resume when the remote
measurement completes.
Select a Measurement Function and Range
The following commands select a measurement function. To enable voltage measurements on
channels 1-4, use:
SENS:FUNC:VOLT ON,(@1:4)
To enable voltage measurements on channels 1-4, use:
SENS:FUNC:CURR ON,(@2)
