[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:STARt[:LEVel] <
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:STARt[:LEVel]? [MIN|MAX,] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:STARt[:LEVel] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:STARt[:LEVel]? [MIN|MAX,] <
Specifies the initial and final current or voltage level of the trapezoid for Arb sequence steps.
Parameter
Current: 0 - maximum|MIN|MAX, *RST MIN
Voltage: 0 - maximum|MIN|MAX, *RST MIN
The maximum value varies, depending on the current or voltage
rating of the power module.
Step 0 - 99, *RST 0
Programs a start- and end-level current: ARB:CURR:TRAP:STAR 1,(@1)
Programs a start- and end- level voltage: ARB:VOLT:TRAP:STAR 1,(@1)
Programs a start- and end-level for step 0: ARB:SEQ:STEP:CURR:TRAP:STAR 1, 0,(@1)
[SOURce:]ARB:CURRent:TRAPezoid:STARt:TIMe <
[SOURce:]ARB:CURRent:TRAPezoid:STARt:TIMe? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:TRAPezoid:STARt:TIMe<
[SOURce:]ARB:VOLTage:TRAPezoid:STARt:TIMe? [MIN|MAX,] (@<chanlist>)
Specifies the delay in seconds after the trigger is received, but before the rising ramp occurs.
Referenced to t0 in the Trapezoid diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:STARt:TIMe <
[SOURce:]ARB:SEQuence:STEP:CURRent:TRAPezoid:STARt:TIMe? [MIN|MAX,] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:STARt:TIMe <
[SOURce:]ARB:SEQuence:STEP:VOLTage:TRAPezoid:STARt:TIMe? [MIN|MAX,] <
Specifies the delay in seconds after the trigger is received, but before the rising ramp occurs for Arb
Sequence steps.
Parameter
0 – 262.144 | MIN | MAX, *RST 0
Step 0 - 99, *RST 0
Programs a start time for the current trapezoid: ARB:CURR:TRAP:STAR:TIM 1,(@1)
Programs a start time for the voltage trapezoid: ARB:VOLT:TRAP:STAR:TIM 1,(@1)
Programs a start time for step 0: ARB:SEQ:STEP:CURR:TRAP:STAR:TIM 1, 0,(@1)
