Test Record Form - Keysight N6763A and N6765A
N6763A and N6765A
Test Description
Voltage Programming & Readback
Minimum voltage (Vout):
Voltage measured over interface:
High voltage (Vout):
Voltage measured over interface:
Low Voltage measured over interface:
CV Load Effect:
CV Source Effect:
CV Ripple and Noise
peak-to-peak:
rms:
Transient response
Voltage @ 100 μs:
Voltage @ 100 μs with Option 760/761:
Current Programming & Readback
Minimum current (Iout):
Current measured over interface:
High current (Iout):
Current measured over interface:
Low Current measured over interface:
CC Load Effect:
CC Source Effect:
Test Description
Voltage Programming & Readback Min Voltage:
Voltage Programming & Readback High Voltage:
Voltage Readback Low:
CV Load Effect, Source Effect, Ripple and Noise:
Transient Response:
Current Programming & Readback Min Current:
Current Programming & Readback High Current:
Current Readback Low:
CC Load Effect, Source Effect:
Keysight N6705C Operating and Service Guide
Report Number ______
Model Min. Specs
Constant Voltage Tests
Both +5 mV
Both Vout − 10 mV
Both 19.989 V
Both Vout − 16 mV
Both Vout − 2.1 mV
Both – 2 mV
Both – 0.5 mV
Both N/A
Both N/A
Both – 30 mV
Both – 200 mV
Constant Current Tests
Both + 35 mA
Both Iout − 60 mA
Both 49.935 A
Both Iout − 60 mA
Both Iout − 1.85 mA
Both – 12 mA
Both – 5 mA
N6763A Setting
10 mV, 15 A
20 V, 15 A
2 V 15 A
20 V, 15 A
6 V, from 25 A to 50 A
50 mA, 6V
50 A, 6 V
1.5 A, 6 V
50 A, 6 V
8 Verification and Calibration
Date__________
Results Max. Specs
_______ + 20 mV
_______ Vout + 10 mV
_______ 20.011 V
_______ Vout + 16 mV
_______ Vout + 2.1 mV
_______ + 2 mV
_______ + 0.5 mV
_______ + 5 mV
_______ + 1 mV
_______ + 30 mV
_______ + 200 mV
_______ + 65 mA
_______ Iout + 60 mA
_______ 50.065 A
_______ Iout + 60 mA
_______ Iout + 1.85 mA
_______ + 12 mA
_______ + 5 mA
N6765A Setting
10 mV, 25 A
20 V, 25 A
2 V, 25 A
20 V, 25 A
10 V, from 25 A to 50 A
50 mA, 10 V
50 A, 10 V
1.5 A, 10 V
50 A, 10 V
