7 SCPI Programming Reference
Exponential
Back to Arb Commands
Arb Type
Exponential
[SOURce:]ARB:CURRent:EXPonential:END[:LEVel] <
[SOURce:]ARB:CURRent:EXPonential:END[:LEVel]? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:END[:LEVel] <
[SOURce:]ARB:VOLTage:EXPonential:END[:LEVel]? [MIN|MAX,] (@<chanlist>)
Specifies the ending current or voltage level after the exponential waveform ends. Referenced to I1
and V1 in the Exponential diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:END[:LEVel] <
[SOURce:]ARB:SEQuence:STEP:CURRent:EXPonential:END[:LEVel]? [MIN|MAX,] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:END[:LEVel] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:EXPonential:END[:LEVel]? [MIN|MAX,] <
Specifies the ending current or voltage level after the exponential waveform ends for Arb sequence
steps.
Parameter
Current: 0 - maximum|MIN|MAX, *RST MIN
Voltage: 0 - maximum|MIN|MAX, *RST MIN
The maximum value varies, depending on the current or voltage
rating of the power module.
Step 0 - 99, *RST 0
Programs an end level current: ARB:CURR:EXP:END 1,(@1)
Programs an end level voltage: ARB:VOLT:EXP:END 20,(@1)
Programs an end current for step 0: ARB:SEQ:STEP:CURR:EXP:END 1, 0,(@1)
[SOURce:]ARB:CURRent:EXPonential:STARt[:LEVel] <
[SOURce:]ARB:CURRent:EXPonential:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:EXPonential:STARt[:LEVel] <
[SOURce:]ARB:VOLTage:EXPonential:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
Specifies the initial current or voltage level when the exponential waveform starts. Referenced to I0
and V0 in the Exponential diagrams.
238
Current
value
>, (@<chanlist>)
value
>, (@<chanlist>)
value
>, (@<chanlist>)
value
>, (@<chanlist>)
Voltage
value step#
>, < >, (@<chanlist>)
step#
>, (@<chanlist>)
value step#
>, < >, (@<chanlist>)
step#
>, (@<chanlist>)
Typical Return
<end value>
(none)
