Display shows: "Enter P2 measured data"
Calculate the shunt current (I=V/R) and enter the data. Press Select when done.
Press Next to finish calibration.
Low Range Current Programming - Models N6761A through N6766A
Step 1. Connect only the current measurement terminals of the Keysight 3458A to the output
terminals (see Cal Setup D
Step 2. Select the low-current programming range. The value to program a range must be the
maximum current of the range. This example selects the 100 mA range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Current, Low Range Prog and Meas. Then
select Start.
Step 3. Select the first current calibration point and enter the data. For models N6761A and N6762A
only, wait a minimum of 5 minutes for the output current to stabilize. before entering the data.
Front Panel Menu Reference
Display shows: "Enter P1 measured data" Measure the current with the Keysight
3458A and enter the data.
Press Select when done.
Step 4. Select the second current calibration point and enter the data. Wait a minimum of 30 seconds
for the output current to stabilize
Front Panel Menu Reference
Display shows: "Enter P2 measured data"
Measure the current with the Keysight 3458A and enter the data. Press Select
when done. Press Next to finish calibration.
Low Range Current Measurement - Models N6761A through N6766A
Step 1. Connect only the current measurement terminals of the Keysight 3458A to the output
terminals (see Cal Setup D
Step 2. Select the low-current measurement range. The value to program a range must be the
maximum current of the range. This example selects the 100 mA range of output 1.
Front Panel Menu Reference
From the Calibration menu, select Current, Low Range Measurement. Then
select Start.
Step 3. Select the first current calibration point and enter the data. For models N6761A and N6762A
only, wait a minimum of 5 minutes for the output current to stabilize before entering the data.
Keysight N6705C Operating and Service Guide
without the resistor).
without the resistor).
8 Verification and Calibration
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
CAL:CURR 0.1, (@1)
SCPI Command
CAL:LEV P1
*OPC?
CAL:DATA <data>
SCPI Command
CAL:LEV P2
*OPC?
CAL:DATA <data>
SCPI Command
CAL:CURR:MEAS 0.1, (@1)
