[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:END:TIMe <
[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:END:TIMe? [MIN|MAX,] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:END:TIMe<
[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:END:TIMe? [MIN|MAX,] <
Specifies the time in seconds, after the ramp completes, that the ending current or voltage level
persists for Arb sequence steps.
Parameter
0 – 262.144 | MIN | MAX, *RST 0
Step 0 - 99, *RST 0
Programs an end time for the current ramp: ARB:CURR:RAMP:END:TIM 2,(@1)
Programs an end time for the voltage ramp:ARB:VOLT:RAMP:END:TIM 2,(@1)
Programs an end time for step 0: ARB:SEQ:STEP:CURR:RAMP:END:TIM 2, 0,(@1)
[SOURce:]ARB:CURRent:RAMP:RTIMe <
[SOURce:]ARB:CURRent:RAMP:RTIMe? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:RAMP:RTIMe<
[SOURce:]ARB:VOLTage:RAMP:RTIMe? [MIN|MAX,] (@<chanlist>)
Specifies the rise time of the ramp in seconds. Referenced to t1 in the Ramp diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:RTIMe <
[SOURce:]ARB:SEQuence:STEP:CURRent:RAMP:RTIMe? [MIN|MAX,] <
[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:RTIMe <
[SOURce:]ARB:SEQuence:STEP:VOLTage:RAMP:RTIMe? [MIN|MAX,] <
Specifies the rise time of the ramp in seconds for Arb sequence steps.
Parameter
0 – 262.144 | MIN | MAX, *RST 1
Step 0 - 99, *RST 0
Programs a rise time for the current ramp: ARB:CURR:RAMP:RTIM 10,(@1)
Programs a rise time for the voltage ramp: ARB:VOLT:RAMP:RTIM 10,(@1)
Programs a rise time for step 0: ARB:SEQ:STEP:CURR:RAMP:RTIM 10, 0,(@1)
[SOURce:]ARB:CURRent:RAMP:STARt[:LEVel] <
[SOURce:]ARB:CURRent:RAMP:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:RAMP:STARt[:LEVel] <
[SOURce:]ARB:VOLTage:RAMP:STARt[:LEVel]? [MIN|MAX,] (@<chanlist>)
Specifies the initial current or voltage before the ramp occurs. Referenced to I0 and V0 in the Ramp
diagrams.
Keysight N6705C Operating and Service Guide
value
>, <
value
>, <
value
>, (@<chanlist>)
value
>, (@<chanlist>)
value step#
>, <
value step#
>, <
value
>, (@<chanlist>)
value
>, (@<chanlist>)
7 SCPI Programming Reference
step#
>, (@<chanlist>)
step#
>, (@<chanlist>)
step#
>, (@<chanlist>)
step#
>, (@<chanlist>)
Typical Return
<end time>
(none)
>, (@<chanlist>)
step#
>, (@<chanlist>)
>, (@<chanlist>)
step#
>, (@<chanlist>)
Typical Return
<rise time>
(none)
